Framery 2Q Huddle
2. Install the roof cover panel to the back half of the roof with 4x30 screws (6 pcs).
Note: Place the countersunk holes upwards. Use the existing screw holes.
Note: Do not lean against the roof. Make sure that your ladder is high enough.
Note: If you installed the power cord to the roof, guide it through the roof cover
panel hole and into the groove before setting the roof cover panel into place.
Make sure that the power cord is not damaged during the installation.
15.2 Install the roof cover plates
Reinstall the cover plates (16 pcs) to the roof with 4x30 screws (16 pcs).
Note: Place the countersunk holes upwards. Use the existing screw holes.
Installation instructions
info@frameryacoustics.com
167
