Framery 2Q - Install the USB Cord into the Strike Plate-Side Glass Frame (Optional)

Framery 2Q Huddle
10.3.1 Install the USB cord into the strike plate-side glass frame (optional)
1. Remove the protective plastic approximately 100 mm (4 in) from the top and bottom of
the aluminum frame of the strike plate-side glass.
2. Guide the customer supplied USB cord in through the hole behind the strike plate and
out through the U-profile at the top edge of the strike plate-side glass frame.
Note: Make sure the USB-A connector of the cord is at the top of the
aluminum frame.
Installation instructions
info@frameryacoustics.com
73
