Framery 2Q Huddle
3. Lay down the joined half of the roof and lift it up to stand on the other side.
4. Install the other support plate with steel colored M6x20 screws (4 pcs). Use a hex key
to fully tighten the screws.
Note: Pull the roof modules straight to fit the support plate into place. Bend the
roof modules further to install the screws, if needed.
Installation instructions
info@frameryacoustics.com
25
