Framery 2Q Huddle
4. Lift the roof carefully into place.
Warning: Heavy object, risk of injury! Follow the regulations for safe lifting.
Lifting requires four people. Do not go under the roof until the fixing bolts are
installed.
Warning: Keep the installation area clear of obstacles that you may stumble
over.
Note: Make sure that the ABS strips meet at the outer sides of the roof and the
wall modules.
Note: Make sure that the guide pin is in the installation hole in the roof.
5. Install M8x35 bolts (4 pcs each side) and M8 washers (4 pcs each side). Tighten the
screws by hand.
44
Installation instructions
