Specications
The foam system is available in various system models.
Control Module
Supply Power: 12/24 VDC
Supply Current: 0.3 Amps (1 Amp Maximum)
Dimensions: 4 7/8" by 4 7/8" (TFC100 is 4 1/4" by 4 1/4")
Foam Pump Assembly
Supply Power: 12/24 VDC
Pump Motor: Power from Foam Pump Control Box High Current Terminals
Electronics: Power from Control Module
Dimensions: Refer to Table 2. Foam Pump Assembly Dimensions
Pump Motor Power: Refer to Table 3 Specication
Pressure Relief Valve: 400 PSI (2758 kPa) Factory Set (600 PSI for TFC _2.1)
Pump Oil: Triplex Plunger Pump Crankcase Oil - # AR64516
14.5 oz for 1.6, 2.1 and 2.6 GPM pump; 15 oz for 3.5, 5.0, 6.2, 6.5 GPM pump
Electric Flush Valve (TFC100/200/300 Only)
Supply Power: 12/24 VDC from Foam Pump Control Box
Supply Current: 3.5 Amps at 12 VDC Maximum (1.75 at 24 Volts)
Electric ABF Selector Valve (TFC400 Only)
Supply Power: 12/24 VDC
Supply Current: 3.5 Amps at 12 VDC Maximum (1.75 at 24 Volts)
Flow Sensors
Type: Paddlewheel
Sensor Material: Acetal (Delrin) with Stainless Steel (316) Shaft
Excitation Voltage: 5 VDC
Summing Box
Supply Power: 12/24 VDC from Control Module
Dimensions: 5.8" by 3.7" by 1.9"
Table 2. Foam Pump Assembly Dimensions
Pump GPM Length Width Height Notes
1.6, 2.6 19 1/2" 10" 8 7/8"
Clearance may be required for calibration handle to open.
Larger motors need some fan intake clearance 1/2".
2.1 22 1/2" 10" 8 7/8"
3.5, 5.0, 6.2, 6.5 23 1/2" 10 1/4" 8 7/8"
