Table 3. Direct Injection Foam Proportioning System Specications
System
The TurboFoam Proportioning System has been tested and is certied to be accurate throughout the
specications provided in Table 3.
This foam proportioning system is compatible with any foam concentrate within the limits determined
by performing the Calibrate Foam Concentrate Pump procedures found in this manual.
FOAM CONCENTRATE PUMP
1.6 GPM 2.1 GPM 2.6 GPM 3.5 GPM 5.0 GPM 6.2 GPM 6.5 GPM
SYSTEM
MODELS
TFC116
TFC216
TFC316
TFC416
TFC121
TFC221
TFC321
TFC126
TFC226
TFC326
TFC426
TFC135
TFC235
TFC335
TFC435
TFC150
TFC250
TFC350
TFC450
TFC162
TFC262
TFC362
TFC462
TFC165
TFC265
TFC365
TFC465
SPECIFICATION
PUMP SIZE
GPM (LPM) 1.6 (6.06) 2.1 (7.95) 2.6 (9.84) 3.5 (13.25) 5.0 (18.93) 6.2 (23.47) 6.5 (24.61)
MOTOR SIZE
(HORSE POWER) 1/3 1 1/2 3/4 1 1 1
DC VOLTAGE 12 or 24 12 or 24 12 or 24 12 or 24 12 or 24 12 24
MAX CURRENT
(AMPS) 36 or 18 90 or 45 50 or 25 68 or 34 78 or 39 90 45
CLASS A FOAM
RANGE: 0.1 to 1.0%
@ 0.1%
1600 (6057) 2100 (7950) 2600 (9842) 3500 (13249) 5000 (18927) 6200 (23470) 6500 (24605)
@ 0.3%
533 (2019) 700 (2650) 867 (3282) 1167 (4416) 1667 (6309) 2067 (7824) 2167 (8202)
@ 0.5%
320 (1211) 420 (1590) 520 (1968) 700 (2650) 1000 (3785) 1240 (4694) 1300 (4921)
@ 1.0%
160 (606) 260 (984) 260 (984) 350 (1325) 500 (1893) 620 (2347) 650 (2461)
CLASS B FOAM
RANGE: 0.5 to 10%
@ 0.5%
320 (1211) N/A 520 (1968) 700 (2650) 1000 (3785) 1240 (4694) 1300 (4921)
@ 3.0%
53 (202) N/A 87 (328) 117 (442) 167 (631) 207 (782) 217 (820)
@ 6.0%
27 (101) N/A 43 (164) 58 (221) 83 (315) 103 (391) 108 (410)
@ 10%
16 (61) N/A 26 (98) 35 (133) 50 (189) 62 (235) 65 (246)
