13
Click [Next >]
The preliminary settings / calibration parameters are displayed:
five measured values M1 - M5 for each power source
-
Welding current [A]
-
Welding voltage [V]
For the wirefeeder, enter five wire speed measured values M1 - M5 [m/min]:
The measured value M5 is the maximum value for the wirefeeder.
Press the Tab key to enter the other measured values.
14
Click [Next >]
The preliminary settings / general measurement data are displayed:
-
Ambient temperature [° C]
-
Mains voltage [V]
-
Open circuit voltage U
S
[V]
If no data is displayed, it can be found by clicking on [Start measuring pro-
cess].
If there is still no data displayed, check the F2 and F3 fuses on the back of
the calibration system.
15
Carry out a visual inspection of the welding system and the calibration sys-
tem, according to the calibration instructions
16
If the visual inspection does not reveal any defects, select [Click here]
17
Click [Next >]
The summary of the calibration process is displayed.
18
Define the calibration class:
o Precision
o Standard
19
Click [Start automatic calibration process]
The calibration process starts.
When a calibration process is active
-
A corresponding notification is displayed
-
The [Interrupt calibration] button is available
-
All measuring points are checked one after the other
-
Current measured values are displayed
-
A progress bar with the remaining time is displayed
If the calibration process is interrupted before the welding wire has been cal-
ibrated, a corresponding notification is displayed.
