8
Click on [Add]
or
select current client from the list shown
Under Others, inventory numbers, order numbers and observations can be
entered.
9
Click [Next >]
The preliminary settings / device selection are displayed.
10
Under Settings, select:
o Fronius devices
11
Select TransTig 170 / 210
12
Click [External start with calibration system]
13
Enter the serial number of the TT 170 / 210 in the box
14
Click [Next >]
The preliminary settings / general measurement data are displayed.
15
Click [Start measuring process]
The following data is displayed:
-
Ambient temperature [° C]
-
Mains voltage [V]
-
Open circuit voltage U
S
[V]
IMPORTANT! The mains voltage displayed is incorrect!
With single-phase machines, the mains voltage must be measured manually
using a FLUKE measuring device, and entered!
16
Measure the mains voltage
17
Enter the mains voltage measured
18
Measure the open circuit voltage, key in
, click
[Start measurement]
19
[ ] Enable In Use and enter the measuring device used under External meas-
uring equipment
20
Carry out a visual inspection of the welding system and the calibration sys-
tem, according to the calibration instructions
21
If the visual inspection does not reveal any defects, select [Click here]
80
