Fronius TPS 600i - TPS 400 I LSC ADV;MV;Nc

213
EN
TPS 400i LSC
ADV /MV/nc
1) Interface to a 230/400 V, 50 Hz public grid
2) An emission class A device is not designed for use in residential areas supplied
with power from a public low-voltage grid.
The electromagnetic compatibility can be influenced by conducted or radiated ra-
dio frequencies.
Mains voltage (U
1
) 3 x 200 V 230 V
Max. effective primary current (I
1eff
) 30.5 A 26.4 A
Max. primary current (I
1max
) 48.2 A 41.6 A
Mains fuse protection 35 A slow-blow
Mains voltage (U
1
) 3 x 380 V 400 V 460 V
Max. effective primary current (I
1eff
) 16.2 A 15.5 A 14.0 A
Max. primary current (I
1max
) 25.5 A 24.4 A 22.1 A
Mains fuse protection 35 A slow-blow
Mains voltage tolerance -10 / +15%
Mains frequency 50/60 Hz
Cos phi (1) 0.99
Max. permissible mains impedance Z
max
on
PCC
1)
45 mOhm
Recommended earth-leakage circuit breaker Type B
Welding current range (I
2
)
MIG/MAG 3 - 400 A
TIG 3 - 400 A
Rod electrode 10 - 400 A
Welding current at 10 min/40 °C (104 °F) 40% 60% 100%
U
1
= 200 - 230 V 400 A 360 A 320 A
U
1
= 380 - 460 V 400 A 360 A 320 A
Output voltage range according to standard characteristic
(U
2
)
MIG/MAG 14.2 - 34.0 V
TIG 10.1 - 26.0 V
Rod electrode 20.4 - 36.0 V
Open circuit voltage (U
0
peak / U
0
r.m.s) 67 V
Degree of protection IP 23
Type of cooling AF
Overvoltage category III
Pollution level according to IEC60664 3
EMC device class A
2)
Safety symbols S, CE, CSA
Dimensions l x w x h 706 x 300 x 720 mm/27.8 x 11.8 x 28.4 in.
Weight 63.6 kg / 140.2 lb.
Max. noise emission (LWA) 77 dB (A)
