219
EN
TPS 600i /nc
1) Interface to a 230/400 V, 50 Hz public grid
2) Discuss the matter with the grid operator before connecting the device to the public
grid!
3) An emission class A device is not designed for use in residential areas supplied
with power from a public low-voltage grid.
The electromagnetic compatibility can be influenced by conducted or radiated ra-
dio frequencies.
Mains voltage (U
1
) 3 x 380 V 400 V 460 V
Max. effective primary current (I
1eff
) 46.6 A 44.4 A 39.2 A
Max. primary current (I
1max
) 60.1 A 57.3 A 50.6 A
Mains fuse protection 63 A slow-blow
Mains voltage tolerance - 10 / + 15%
Mains frequency 50/60 Hz
Cos phi (1) 0.99
Max. permissible mains impedance Z
max
on PCC
1)
Possible connection
restrictions
2)
Recommended earth-leakage circuit breaker Type B
Welding current range (I
2
)
MIG/MAG 3 - 600 A
TIG 3 - 600 A
Rod electrode 10 - 600 A
Welding current at 10 min/40 °C (104 °F) 60% 100%
U
1
= 380 - 460 V 600 A 500 A
Output voltage range according to standard characteristic (U
2
)
MIG/MAG 14.2 - 44.0 V
TIG 10.1 - 34.0 V
Rod electrode 20.4 - 40.0 V
Open circuit voltage (U
0
peak / U
0
r.m.s) 85 V
Degree of protection IP 23
Type of cooling AF
Overvoltage category III
Pollution level according to IEC60664 3
EMC device class A
3)
Safety symbols S, CE, CSA
Dimensions l x w x h 706 x 300 x 510 mm/27.8 x 11.8 x 20.1 in.
Weight 47.0 kg / 103.6 lb.
Max. shielding gas pressure 7.0 bar / 101.49 psi
Coolant Original Fronius
Max. noise emission (LWA) 83 dB (A)
