Fronius TPS 600i - TPS 600 I;600 V;Nc

220
TPS 600i /600V/nc
Mains voltage (U
1
) 3 x 575 V
Max. effective primary current (I
1eff
) 37.6A
Max. primary current (I
1max
) 48.5 A
Mains fuse protection 63 A slow-blow
Mains voltage tolerance +/-10%
Mains frequency 50/60 Hz
Cos phi (1) 0.99
Recommended earth-leakage circuit breaker Type B
Welding current range (I
2
)
MIG/MAG 3 - 600 A
TIG 3 - 600 A
Rod electrode 10 - 600 A
Welding current at 10 min/40 °C (104 °F) 60% 100%
600 A 500 A
Output voltage range according to standard characteristic (U
2
)
MIG/MAG 14.2 - 44.0 V
TIG 10.1 - 34.0 V
Rod electrode 20.4 - 44.0 V
Open circuit voltage (U
0
peak / U
0
r.m.s) 73 V
Degree of protection IP 23
Type of cooling AF
Overvoltage category III
Pollution level according to IEC60664 3
Safety symbols S, CSA
Dimensions (l x w x h) 706 x 300 x 510 mm
27.8 x 11.8 x 20.1 in.
Weight 42.0 kg
92.6 lb.
Max. shielding gas pressure 7 bar
101.49 psi
Coolant Original Fronius
Max. noise emission (LWA) 83 dB (A)
