Fronius TransPocket 150 - Software Update Via TP Service Tool

76
Software update via TP service tool
Software update
via TP service
tool
Use a USB cable to connect the device
on the mini USB port of the rack to the
PC
TP service tool user interface
Start the software: Press "Connect"
Select the USB port as shown,
e.g. COM26
Select the software to suit the device
type on the rating plate.
The software update starts automatically.
"Update complete" is displayed as soon as
the software has been successfully up-
dated.
DEVICEINFO:
Essential system data and PC board data
1
NOTE! The software update may
cause some error messages to be
temporarily displayed.
Clear the error messages by re-
starting the device. You must al-
low roughly 1 minute for the
capacitors to discharge.
1
2
3
