194
TransTig
4000 Comfort,
TransTig
4000 Comfort MV
Explanation of
footnotes
1)
connected to public mains supply with 230 / 400 V and 50 Hz
2)
d.c. = duty cycle
3)
PCC = interface to the public grid
Dimensions L x W x H (with handle) 560 / 250 / 435 mm
22.0 / 9.8 / 17.1 in.
560 / 250 / 435 mm
22.0 / 9.8 / 17.1 in.
Weight 25,9 kg
57.10 lb.
25,9 kg
57.10 lb.
Mark of conformity S, CE S, CE
TT 2500 Comfort MV TT 3000 Comfort MV
TT 4000 Comfort TT 4000 Comfort MV
Mains voltage 3 x 400 V 3 x 200 - 240 V
3 x 380 - 460 V
Mains voltage tolerance ± 15 % ± 10 %
Mains frequency 50/60 Hz 50/60 Hz
Mains fuse protection (slow-blow) 35 A 63/35 A
Mains connection
1)
Restrictions possible Restrictions possible
Primary continuous power (100% d.c.
2)
) 11.8 kVA 11.5 kVA
Cos phi 0,99 0,99
Welding current range
TIG 3 - 400 A 3 - 400 A
Electrode 10 - 400 A 10 - 400 A
Welding current at
10 min/40 °C (104 °F) 40% d.c.
2)
--
10 min/40 °C (104 °F) 45% d.c.
2)
400 A 400 A
10 min/40 °C (104 °F) 60% d.c.
2)
365 A 360 A
10 min/40 °C (104 °F) 100% d.c.
2)
310 A 300 A
Open circuit voltage 86 V 86 V
Working voltage
TIG 10.1 - 26.0 V 10.1 - 26.0 V
Electrode 20.4 - 36.0 V 20.4 - 36.0 V
Striking voltage (U
p
) 9.5 kV 9.5 kV
The arc striking voltage is suitable for manual operation.
Degree of protection IP 23 IP 23
Type of cooling AF AF
Insulation class F F
EMC emission class
(in accordance with EN/IEC 60974-10)
AA
Dimensions L x W x H (with handle) 625 / 290 / 475 mm
24.6 / 11.4 / 18.7 in.
625 / 290 / 475 mm
24.6 / 11.4 / 18.7 in.
Weight 39.8 kg
87.7 lb.
42.0 kg
92.6 lb.
Mark of conformity S, CE S, CE, CSA
