Preparation Set up and install the power source in accordance with the welding job
Plug in the mains plug
Move the mains switch to the I position
The starting sequence with the Fronius logo, current firmware version and Fronius in-
ternet address is displayed for approx. 1 second:
only with MagicWave for the manual metal arc AC welding process
Unit 1
Setting range -5 - +5
Factory setting 0
-5: highest fusing power, lowest cleaning action
+5: highest cleaning action, lowest fusing power
CAUTION! Risk of injury and damage from electric shock. As soon as the mains
switch is in the "I" position, the tungsten electrode of the welding torch is live.
Make sure that the tungsten electrode does not touch any persons or electrically
conductive or earthed parts (e.g. housing, etc.).
