30
(8) Process button
for selecting the welding process depending on the mode that has been chosen
2-step mode/4-step mode:
automatic cap-shaping;
only available in conjunction with TIG AC welding
TIG AC welding process
TIG DC- welding process
Manual metal arc welding mode:
MMA AC welding process
MMA DC- welding process
MMA DC+ welding process
When a process is selected, the LED on the relevant symbol lights up.
(9) Right arrow key
for navigating in the menu
(10) Mode button
for selecting the mode
2-step mode
4-step mode
Manual metal arc welding
When a mode is selected, the LED on the relevant symbol lights up.
(11) Gas test button
for setting the required shielding gas flow rate on the gas pressure regulator
After pressing this button, gas flows for 30 seconds. Press the button again to stop
the gas flow prematurely.
(12) Adjusting dial
- Turn the adjusting dial to: select welding parameter
- Press the adjusting dial to: confirm a selection in a menu, accept values
(13) Menu button
for calling up the menu in the selected process
(14) Left arrow key
for navigating in the menu
(15) HF (high frequency) ignition indicator
lights up when the HF ignition welding parameter has been set to an interval
for the high frequency pulses
No. Function
