Page #133 background imageLoading...
Page #133 background image
133
EN
Technical data
Special voltages
CAUTION!
An inadequately dimensioned electrical installation can cause serious damage.
The mains lead and its fuse must be dimensioned accordingly.
The technical data shown on the rating plate applies.
MagicWave
1700 / 2200 Job
MW 1700 Job MW 2200 Job
Mains voltage 230 V 230 V
Mains voltage tolerance -20 % / +15 % -20 % / +15 %
Mains frequency 50/60 Hz 50/60 Hz
Mains fuse protection (slow-blow) 16 A 16 A
Mains connection
1)
Restrictions possible No restrictions
Primary continuous power (100% d.c.
2)
) 3.3 kVA 3.7 kVA
Cos phi 0,99 0,99
Welding current range
TIG 3 - 170 A 3 - 220 A
Electrode 10 - 140 A 10 - 180 A
Welding current at
10 min/25 °C (77 °F) 40% d.c.
2)
170 A 220 A
10 min/25 °C (77 °F) 60% d.c.
2)
140 A 180 A
10 min/25 °C (77 °F) 100% d.c.
2)
110 A 150 A
10 min/40 °C (104 °F) 35% d.c.
2)
170 A 220 A
10 min/40 °C (104 °F) 60% d.c.
2)
130 A 170 A
10 min/40 °C (104 °F) 100% d.c.
2)
100 A 150 A
Open circuit voltage 88 V 88 V
Working voltage
TIG 10.1 - 16.8 V 10.1 - 18.8 V
Electrode 20.4 - 25.6 V 20.4 - 27.2 V
Striking voltage (U
p
) 9.5 kV 9.5 kV
The arc striking voltage is suitable for manual operation.
Degree of protection IP 23 IP 23
Type of cooling AF AF
Insulation class B B
EMC emission class
(in accordance with EN/IEC 60974-10)
A A
Dimensions L x W x H (with handle) 485 / 180 / 344 mm
19.1 / 7.1 / 13.6 in.
485 / 180 / 390 mm
19.1 / 7.1 / 15.4 in.
Weight (without handle) 14.6 kg
30.8 lb.
17.4 kg
38.3 lb.
Weight (with handle) 15 kg
33 lb.
17.8 kg
39.2 lb.
Mark of conformity S, CE S, CE
