55
EN
Start-up
Safety
WARNING!
An electric shock can be fatal.
If the device is plugged into the mains during installation, there is a high risk of very serious
injury and damage.
► Only carry out work on the device if the mains switch is in the "O" position.
► Only carry out work on the charger when it has been disconnected from the mains sup-
ply.
Remarks on the
cooling unit
We recommend using a cooling unit for the following applications and situations:
- JobMaster TIG welding torch
- Robot welding
- Hosepacks over 5 m long
- TIG AC welding
- In general, where welding is performed in higher power ranges
The cooling unit is powered from the power source. The cooling unit is ready for operation
when the mains switch of the power source is in the "I" position.
More information on the cooling unit can be found in the operating instructions for the cool-
ing unit.
General This section describes how to commission the power source:
- for the main TIG welding application
- with reference to a standard configuration for a TIG welding device.
The standard configuration consists of the following system components:
- power source
- cooling unit
- TIG manual welding torch
- pressure regulator
- gas cylinder
- gas cylinder holder
- trolley
The steps set out below provide an overview of how to commission the power source.
For detailed information about the individual steps, please refer to the operating instruc-
tions for the system components.
Connecting the
gas cylinder
WARNING!
If gas cylinders topple over, there is a risk of very serious injury and damage.
► Place gas cylinders on a solid, level surface in such a way that they remain stable
► Secure gas cylinders to prevent them from toppling over: fix the safety strap at the
same height as the top part of the cylinder
► Never fix the safety strap around the neck of the cylinder
Follow the gas cylinder manufacturer's safety instructions.
