134
MagicWave
2500 / 3000 Job
MagicWave
2500 / 3000 Job
MV
MW 2500 Job MW 3000 Job
Mains voltage 3 x 400 V 3 x 400 V
Mains voltage tolerance ± 15 % ± 15 %
Mains frequency 50/60 Hz 50/60 Hz
Mains fuse protection (slow-blow) 16 A 16 A
Mains connection
1)
Z
max
at PCC
3)
= 122 mOhm
Z
max
at PCC
3)
= 87 mOhm
Primary continuous power (100% d.c.
2)
) 4.7 kVA 5.5 kVA
Cos phi 0,99 0,99
Welding current range
TIG 3 - 250 A 3 - 300 A
Electrode 10 - 250 A 10 - 300 A
Welding current at
10 min/40 °C (104 °F) 35% d.c.
2)
- 300 A
10 min/40 °C (104 °F) 40% d.c.
2)
250 A -
10 min/40 °C (104 °F) 100% d.c.
2)
180 A 200 A
Open circuit voltage 89 V 89 V
Working voltage
TIG 10.1 - 20.0 V 10.1 - 22.0 V
Electrode 20.4 - 30.0 V 20.4 - 32.0 V
Striking voltage (U
p
) 10 kV 10 kV
The arc striking voltage is suitable for manual operation.
Degree of protection IP 23 IP 23
Type of cooling AF AF
Insulation class B B
EMC emission class
(in accordance with EN/IEC 60974-10)
A A
Dimensions L x W x H (with handle) 560 / 250 / 435 mm
22.0 / 9.8 / 17.1 in.
560 / 250 / 435 mm
22.0 / 9.8 / 17.1 in.
Weight 26.6 kg
58.64 lb.
28.1 kg
61.95 lb.
Mark of conformity S, CE S, CE
MW 2500 Job MV MW 3000 Job MV
Mains voltage 3 x 200 - 240 V
3 x 400 - 460 V
1 x 200 - 240 V
3 x 200 - 240 V
3 x 400 - 460 V
1 x 200 - 240 V
Mains voltage tolerance ± 10 % ± 10 %
Mains frequency 50/60 Hz 50/60 Hz
Mains fuse protection (slow-blow)
3 x 400 - 460 V
3 x 200 - 240 V
1 x 200 - 240 V
16 A
32 A
32 A
16 A
32 A
32 A
Mains connection
1)
Z
max
at PCC
3)
= 122 mOhm
Z
max
at PCC
3)
= 87 mOhm
