Fronius TransTig 800 Job User Manual

136
MagicWave
4000 / 5000 Job
MV
Mains fuse protection (slow-blow) 35 A 35 A
Mains connection
1)
Restrictions possible Restrictions possible
Primary continuous power (100% d.c.
2)
) 15.5 kVA 17.9 kVA
Cos phi 0,99 0,99
Welding current range
TIG 3 - 400 A 3 - 500 A
Electrode 10 - 400 A 10 - 440 A
Welding current at
10 min/40 °C (104 °F) 40% d.c.
2)
- 500 A
10 min/40 °C (104 °F) 45% d.c.
2)
400 A -
10 min/40 °C (104 °F) 60% d.c.
2)
365 A 440 A
10 min/40 °C (104 °F) 100% d.c.
2)
310 A 350 A
Open circuit voltage 90 V 90 V
Working voltage
TIG 10.1 - 26.0 V 10.1 - 30.0 V
Electrode 20.4 - 36.0 V 20.4 - 37.6 V
Striking voltage (U
p
) 9.5 kV 9.5 kV
The arc striking voltage is suitable for manual operation.
Degree of protection IP 23 IP 23
Type of cooling AF AF
Insulation class F F
EMC emission class
(in accordance with EN/IEC 60974-10)
A A
Dimensions L x W x H (with handle) 625 / 290 / 705 mm
24.6 / 11.4 / 27.8 in.
625 / 290 / 705 mm
24.6 / 11.4 / 27.8 in.
Weight 58.2 kg
128 lb.
58.2 kg
128 lb.
Mark of conformity S, CE S, CE
MW 4000 Job MW 5000 Job
MW 4000 Job MV MW 5000 Job MV
Mains voltage 3 x 200 - 240 V
3 x 380 - 460 V
3 x 200 - 240 V
3 x 380 - 460 V
Mains voltage tolerance ± 10 % ± 10 %
Mains frequency 50/60 Hz 50/60 Hz
Mains fuse protection (slow-blow) 63/35 A 63/35 A
Mains connection
1)
Restrictions possible Restrictions possible
Primary continuous power (100% d.c.
2)
) 13.9 kVA 16.5 kVA
Cos phi 0,99 0,99
Welding current range
TIG 3 - 400 A 3 - 500 A
Electrode 10 - 400 A 10 - 440 A
