SYMBOL DESCRIPTION
z
Outdoor unit
z
Indoor unit
MARK DESCRIPTION
CMP Compressor (Inverter type)
HEX Heat exchanger
FAN 1 Fan 1
FAN 2 Fan 2
ACM Accumulator
OS Oil separator
SCHEX Sub-cool heat exchanger
HPS High pressure sensor
LPS Low pressure sensor
HPSW High pressure sensor switch
4WV 4-way valve
EEV 1 Electric expansion valve 1
EEV 2 Electric expansion valve 2
SV 2 Solenoid valve
Marking (Tube)
TH 1 Discharge temperature thermistor
Blue
TH 3 Outdoor temperature thermistor
–
TH 4 Suction temperature thermistor
Red
TH 5 Heat exchanger (outlet) thermistor
Pink
TH 7 Liquid temperature thermistor
Green
TH 8 Sub-cool heat exchanger (inlet) thermistor
White
TH 9 Sub-cool heat exchanger (outlet) thermistor
Brown
TH 10 Compressor temperature thermistor
–
MARK DESCRIPTION
HEX 21 Heat exchanger
FAN 21 Fan
EEV 21 Electric expansion valve
TH 21 Room temperature thermistor
TH 22 Heat exchanger (inlet) thermistor
TH 23 Heat exchanger (outlet) thermistor
- (03 - 07) -
OUTDOOR UNITS OUTDOOR UNITS
