2-12. IR RECEIVER UNIT
(for CIRCULAR FLOW CASSETTE TYPE)

MODELS: UTY-LBHXD
Cassette type indoor unit can be controlled with wireless remote controller if the IR
receiver unit is used.

FUNCTIONS

ELECTRICAL WIRING
Wire from IR receiver unit
Wiring hole (Indoor unit)
Attach the corner plate
rmly in 5 places
Remote control signal receiver
and Manual Auto button
FILTER Indicator lamp (RED)
OPERATION Indicator lamp
(GREEN)
TIMER Indicator lamp
(ORANGE)
