Fujitsu Airstage J-II Series User Manual

TC : Total Capacity kBtu/h.
Outdoor Temperature
Indoor temperature
61°FDB 64°FDB 68°FDB 70°FDB 72°FDB 75°FDB 79°FDB
(°FDB)
(°FWB) TC TC TC TC TC TC TC
-2.7
-4.0
17.7 17.7 17.7 17.6 17.6 17. 6 17. 5
5.0
3.2
20.5 20.4 20.4 20.3 20.3 20.3 20.2
10.4
8.6
22.8 22.7 22.6 22.6 22.5 22.5 22.4
15.8
14.0
25.0 24.9 24.8 24.8 24.7 24.6 24.5
17. 0
15.0
25.4 25.3 25.2 25.1 25.1 25.0 24.9
23.0
21.2
28.2 28.1 28.0 2 7.9 2 7.8 2 7.7 2 7.6
26.6
24.8
29.7 29.6 29.4 29.4 29.3 29.2 27.8
30.2
28.4
31.2 31.1 30.9 30.8 30.8 30.4 2 7.8
32.0
30.2
32.1 31.9 31.6 31.5 31.4 30.4 2 7.8
35.6
33.8
33.6 33.4 33.1 33.0 32.3 30.4 2 7.8
41.0
39.2
36.1 36.0 35.3 34.0 32.6 30.7 28.1
47.0
43.0
37.9 37.6 35.3 34.0 32.6 30.7 2 8 .1
48.2
46.0
39.1 37.9 35.3 34.0 32.6 30.7 28.1
53.6
51.1
39.8 37.9 35.3 34.0 32.6 30.7 28.1
59.0
56.3
39.8 37.9 35.3 34.0 32.6 30.7 28.1
Outdoor Temperature
Indoor temperature
61°FDB 64°FDB 68°FDB 70°FDB 72°FDB 75°FDB 79°FDB
(°FDB)
(°FWB) TC TC TC TC TC TC TC
-2.7
-4.0
14.1 14.1 14.1 14.0 14.0 14.0 13.9
5.0
3.2
16.3 16.2 16.2 16.1 16.1 16.1 16.0
10.4
8.6
18.1 18.1 18.0 18.0 17.9 17. 9 17.8
15.8
14.0
19.8 19.8 19.7 19.7 19.6 19.5 19.4
17. 0
15.0
20.2 20.1 20.0 19.9 19.9 19.8 19.8
23.0
21.2
22.4 22.3 22.2 22.1 2 2.1 22.0 21.9
26.6
24.8
23.6 23.5 23.3 23.3 23.3 23.2 22 .1
30.2
28.4
24.8 24.7 24.5 24.4 24.4 24.1 2 2.1
32.0
30.2
25.5 25.3 25.1 25.0 25.0 24.1 22 .1
35.6
33.8
26.7 26.5 26.3 26.2 25.6 24.1 22 .1
41.0
39.2
28.7 28.6 28.0 27. 0 25.9 24.4 22.3
47.0
43.0
30.1 29.9 28.0 27.0 25.9 24.4 22.3
48.2
46.0
31.1 3 0.1 28.0 27.0 25.9 24.4 22.3
53.6
51.1
31.6 30.1 28.0 27.0 25.9 24.4 22.3
59.0
56.3
31.6 30.1 28.0 27.0 25.9 24.4 22.3
Outdoor Temperature
Indoor temperature
61°FDB 64°FDB 68°FDB 70°FDB 72°FDB 75°FDB 79°FDB
(°FDB)
(°FWB) TC TC TC TC TC TC TC
-2.7
-4.0
10.4 10.4 10.4 10.3 10.3 10.3 10.3
5.0
3.2
12 .1 12.0 12.0 11.9 11.9 11.9 11.9
10.4
8.6
13.4 13.4 13.3 13.3 13.2 13.2 13.2
15.8
14.0
14.7 14.6 14.6 14.6 14.5 14.4 14.4
17. 0
15.0
15.0 14.9 14.8 14.8 14.8 14.7 14.6
23.0
21.2
16.6 16.5 16.5 16.4 16.3 16.3 16.2
26.6
24.8
17. 5 17.4 17.3 17. 3 17.2 17. 2 16.3
30.2
28.4
18.4 18.3 18.2 18 .1 18.1 17.9 16.3
32.0
30.2
18.9 18.7 18.6 18.5 18.5 17.9 16.3
35.6
33.8
19.7 19.6 19.5 19.4 19.0 17.9 16.3
41.0
39.2
21.3 21.2 20.8 20.0 19.2 18.0 16.5
47.0
43.0
22.3 22 .1 20.8 20.0 19.2 18.0 16.5
48.2
46.0
23.0 22.3 20.8 20.0 19.2 18.0 16.5
53.6
51.1
23.4 22.3 20.8 20.0 19.2 18.0 16.5
59.0
56.3
23.4 22.3 20.8 20.0 19.2 18.0 16.5
HEATING CAPACITY
in kBtu/h
8-2. CIRCULAR FLOW CASSETTE TYPE

MODEL : AUUB18TLAV1

MODEL : AUUB24TLAV1

MODEL : AUUB30TLAV1
- (02 - 53) -
MODEL SELECTION MODEL SELECTION
