TC : Total Capacity kBtu/h.
IP : Input Power kW (Compressor + Outdoor fan motor).
The data is based on the following conditions. Pipe length : 25 ft. (7.5 m) , Height dierence : 0 ft. (0 m).
COOLING CAPACITY
in kBtu/h
4. CAPACITY TABLE COOLING (OUTDOOR UNIT)
MODEL : AOU36RLAVM
z
Capacity : 36 kBtu/h (3 ton)
Total rated
cooling capacity
of indoor unit
Outdoor
temperature
Indoor temperature
68
°F
DB 59
°F
WB 73
°F
DB 61
°F
WB 75
°F
DB 63
°F
WB 79
°F
DB 64
°F
WB 80
°F
DB 67
°F
WB 82
°F
DB 68
°F
WB 86
°F
DB 72
°F
WB 90
°F
DB 73
°F
WB
(°FDB) TC IP TC IP TC IP TC IP TC IP TC IP TC IP TC IP
46.8
(130%)
23
29.7 1.36 34.0 1.54 38.2 1.71 40.4 1.80 46.8 2.07 49.0 2 .16 52.4 2.25 53.0 2.26
32
29.7 1.36 34.0 1.54 38.2 1.71 40.4 1.80 46.8 2.07 49.0 2 .16 52.4 2.25 53.0 2.26
41
29.7 1.36 34.0 1.54 38.2 1.71 40.4 1.80 46.8 2.07 49.0 2 .16 52.4 2.25 53.0 2.26
50
29.7 1.36 34.0 1.54 38.2 1.71 40.4 1.80 46.8 2.07 49.0 2 .16 52.4 2.25 53.0 2.26
59
29.7 1.36 34.0 1.54 38.2 1.71 40.4 1.80 46.8 2.08 49.0 2.22 51.8 2.34 52.4 2.36
70
29.7 1.39 34.0 1.63 38.2 1.90 40.4 2.05 46.8 2.51 47.9 2.58 50.0 2.65 50.6 2.66
73
29.7 1.45 34.0 1.71 38.2 2.00 40.4 2.15 46.8 2.64 47.4 2.67 49.5 2.73 50 .1 2.74
77
29.7 1.55 34.0 1.83 38.2 2 .13 40.4 2.30 46.3 2.76 46.8 2.78 48.9 2.84 49.4 2.85
81
29.7 1.65 34.0 1.95 38.2 2.27 40.4 2.45 45.6 2.87 46 .1 2.89 48.2 2.95 48.8 2.96
86
29.7 1.78 34.0 2 .11 38.2 2.46 40.4 2.65 44.8 3.01 45.3 3.02 47.4 3.08 47.9 3.10
91
29.7 1.92 34.0 2.27 38.2 2.65 40.4 2.86 44.0 3.15 44.5 3 .16 46.6 3.22 47.1 3.23
95
29.7 2.04 34.0 2.41 38.2 2.82 40.4 3.04 43.3 3.27 43.8 3.28 45.9 3.35 46.5 3.37
99
29.7 2.16 34.0 2.56 38.2 3.00 40.4 3.24 42.7 3.40 43.2 3.42 45.3 3.49 45.8 3.50
104
29.7 2.33 34.0 2.78 38.2 3.26 40.4 3.52 41.9 3.57 42.4 3.59 44.4 3.66 45.0 3.67
109
29.7 2.53 34.0 3.01 38.2 3.53 39.6 3.69 41.1 3.74 41.6 3.76 43.6 3.83 4 4.1 3.85
115
29.7 2.78 34.0 3.31 3 8.1 3.87 38.6 3.89 4 0.1 3.95 40.6 3.96 42.6 4.04 43.2 4.05
43.2
(120%)
23
27.4 1.26 31.3 1.43 35.3 1.59 37.3 1.67 43.2 1.92 45.2 2.00 51.2 2.23 51.8 2.24
32
27.4 1.26 31.3 1.43 35.3 1.59 37.3 1.67 43.2 1.92 45.2 2.00 51.2 2.23 51.8 2.24
41
27.4 1.26 31.3 1.43 35.3 1.59 37.3 1.67 43.2 1.92 45.2 2.00 51.2 2.23 51.8 2.24
50
27.4 1.26 31.3 1.43 35.3 1.59 37.3 1.67 43.2 1.92 45.2 2.00 51.2 2.23 51.8 2.24
59
27.4 1.26 31.3 1.43 35.3 1.59 37.3 1.67 43.2 1.92 45.2 2.00 50.8 2.31 51.3 2.33
70
27.4 1.29 31.3 1.47 35.3 1.71 3 7. 3 1.84 43.2 2.24 45.2 2.39 49.0 2.62 49.5 2.63
73
27.4 1.33 31.3 1.55 35.3 1.80 37. 3 1.93 43.2 2.36 45.2 2.51 48.5 2.70 49.1 2.71
77
27.4 1.41 31.3 1.65 35.3 1.92 37.3 2.06 43.2 2.52 45.2 2.68 47.9 2.81 48.4 2.82
81
27.4 1.50 31.3 1.76 35.3 2.05 37. 3 2.20 43.2 2.68 45.2 2.86 47.3 2.92 47.8 2.93
86
27.4 1.62 31.3 1.91 35.3 2.21 37.3 2.38 43.2 2.90 44.4 3.00 46.5 3.06 47.0 3.07
91
27.4 1.75 31.3 2.06 35.3 2.39 37.3 2.57 43.1 3 .12 43.6 3 .14 45.6 3 .19 46.2 3.21
95
27.4 1.85 31.3 2 .18 35.3 2.54 3 7. 3 2.73 42.5 3.24 43.0 3.25 45.0 3.32 45.5 3.34
99
27.4 1.96 31.3 2.32 35.3 2.69 37.3 2.90 41.9 3.37 42.4 3.39 44.4 3.46 44.9 3.47
104
27.4 2.11 31.3 2.50 35.3 2.92 37. 3 3.15 41.1 3.54 41.6 3.56 43.6 3.63 4 4.1 3.65
109
27.4 2.29 31.3 2.71 35.3 3 .17 37.3 3.41 40.3 3.71 40.8 3.73 42.8 3.80 43.3 3.82
115
27.4 2.51 31.3 2.98 35.3 3.48 37.3 3.75 39.3 3.92 39.8 3.94 41.8 4.01 42.3 4.02
39.6
(110%)
23
25.1 1.17 28.7 1.32 32.4 1.47 34.2 1.55 39.6 1.77 41.4 1.85 48.7 2.15 50.5 2.22
32
25.1 1.17 28.7 1.32 32.4 1.47 34.2 1.55 39.6 1.77 41.4 1.85 48.7 2.15 50.5 2.22
41
25.1 1.17 28.7 1.32 32.4 1.47 34.2 1.55 39.6 1.77 41.4 1.85 48.7 2.15 50.5 2.22
50
25.1 1.17 28.7 1.32 32.4 1.47 34.2 1.55 39.6 1.77 41.4 1.85 48.7 2.15 50.5 2.22
59
25.1 1.17 28.7 1.32 32.4 1.47 34.2 1.55 39.6 1.77 41.4 1.85 48.7 2.20 5 0.1 2.29
70
25.1 1.19 28.7 1.35 32.4 1.53 34.2 1.64 39.6 1.99 41.4 2.12 47. 9 2.58 48.4 2.60
73
25.1 1.23 28.7 1.39 32.4 1.61 34.2 1.73 39.6 2.09 41.4 2.23 47.4 2.67 47.9 2.68
77
25.1 1.28 28.7 1.49 32.4 1.72 34.2 1.84 39.6 2.23 41.4 2.38 46.8 2.78 47.3 2.79
81
25.1 1.35 28.7 1.59 32.4 1.83 34.2 1.97 39.6 2.38 41.4 2.53 46.2 2.89 46.7 2.90
86
25.1 1.46 28.7 1.71 32.4 1.98 34.2 2.12 39.6 2.58 41.4 2.74 45.4 3.03 45.9 3.04
91
25.1 1.58 28.7 1.85 32.4 2.14 34.2 2.29 39.6 2.78 41.4 2.96 44.6 3.16 45.1 3.18
95
25.1 1.67 28.7 1.96 32.4 2.27 34.2 2.43 39.6 2.95 41.4 3 .14 44.0 3.29 44.5 3.30
99
25.1 1.77 28.7 2.08 32.4 2.41 34.2 2.58 39.6 3.15 41.4 3.36 43.4 3.42 43.9 3.44
104
25.1 1.90 28.7 2.24 32.4 2.61 34.2 2.80 39.6 3.42 40.7 3.53 42.6 3.59 43 .1 3.61
109
25.1 2.06 28.7 2.43 32.4 2.82 34.2 3.04 39.4 3.68 39.9 3.70 41.8 3.77 42.3 3.78
115
25.1 2.26 28.7 2.66 32.4 3 .10 34.2 3.34 38.5 3.88 39.0 3.90 40.9 3.97 41.4 3.99
36.0
(100%)
23
22.8 1.07 26.1 1.21 29.4 1.35 31.1 1.42 36.0 1.62 3 7.7 1.69 44.2 1.96 45.9 2.03
32
22.8 1.07 26.1 1.21 29.4 1.35 31.1 1.42 36.0 1.62 3 7.7 1.69 44.2 1.96 45.9 2.03
41
22.8 1.07 26.1 1.21 29.4 1.35 31.1 1.42 36.0 1.62 3 7.7 1.69 44.2 1.96 45.9 2.03
50
22.8 1.07 26.1 1.21 29.4 1.35 31.1 1.42 36.0 1.62 3 7.7 1.69 44.2 1.96 45.9 2.03
59
22.8 1.07 26.1 1.21 29.4 1.35 31.1 1.42 36.0 1.62 3 7.7 1.69 44.2 1.96 45.9 2.03
70
22.8 1.09 26.1 1.23 29.4 1.38 31.1 1.46 36.0 1.76 3 7.7 1.86 44.2 2.32 45.9 2.44
73
22.8 1.13 2 6.1 1.27 29.4 1.43 31.1 1.53 36.0 1.85 3 7.7 1.96 44.2 2.44 45.9 2.57
77
22.8 1.18 26.1 1.33 29.4 1.53 31.1 1.64 36.0 1.97 3 7.7 2.09 44.2 2.60 45.9 2.74
81
22.8 1.22 26.1 1.42 29.4 1.63 31.1 1.74 36.0 2.10 3 7.7 2.23 44.2 2.77 45.4 2.87
86
22.8 1.31 26.1 1.53 29.4 1.76 31.1 1.88 36.0 2.27 3 7.7 2.41 44.2 2.99 44.7 3.01
91
22.8 1.41 26.1 1.65 29.4 1.90 31.1 2.03 36.0 2.45 37.7 2.60 43.4 3 .13 43.9 3 .14
95
22.8 1.50 26.1 1.75 29.4 2.02 31.1 2.16 36.0 2.61 37.7 2.76 42.8 3.25 43.3 3.26
99
22.8 1.59 26.1 1.86 29.4 2.14 31.1 2.29 36.0 2.77 37.7 2.94 42.2 3.39 42.7 3.40
104
22.8 1.71 26 .1 1.99 29.4 2.31 31.1 2.47 36.0 3.00 37.7 3.19 41.5 3.56 42.0 3.57
109
22.8 1.84 26.1 2 .16 29.4 2.50 31.1 2.68 36.0 3.25 37.7 3.46 40.7 3.73 41.2 3.75
115
22.8 2.01 2 6 .1 2.37 29.4 2.74 31.1 2.94 36.0 3.58 37.7 3.81 39.8 3.93 40.3 3.95
- (02 - 12) -
