Fujitsu Airstage J-II Series User Manual

TC : Total Capacity kBtu/h.
SHC : Sensible Heat Capacity kBtu/h.
COOLING CAPACITY
in kBtu/h
7. CAPACITY TABLE COOLING (INDOOR UNIT)
7-1. COMPACT CASSETTE TYPE

MODEL : AUUA4TLAV1

MODEL : AUUA7TLAV

MODEL : AUUA9TLAV

MODEL : AUUA12TLAV
Outdoor
temperature
Indoor temperature
68°FDB / 59 °FWB 73°FDB / 61 °FWB 75°FDB / 63 °FWB 79°FDB / 64 °FWB 80°FDB / 67 °FWB 82°FDB / 68 °FWB 86°FDB / 72 °FWB 90°FDB / 73 °FWB
(°FDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
50
7.6 6.0 8.7 7.3 9.8 7. 6 10.4 8.7 12.0 8.5 12.6 8.9 14.7 9.3 15.3 10.3
59
7.6 6.0 8.7 7.3 9.8 7. 6 10.4 8.7 12.0 8.5 12.6 8.9 14.7 9.3 15.3 10.3
70
7.6 6.0 8.7 7.3 9.8 7. 6 10.4 8.7 12.0 8.5 12.6 8.9 14.7 9.3 15.3 10.3
73
7.6 6.0 8.7 7.3 9.8 7. 6 10.4 8.7 12.0 8.5 12.6 8.9 14.7 9.3 15.2 10.3
77
7.6 6.0 8.7 7.3 9.8 7. 6 10.4 8.7 12.0 8.5 12.6 8.9 14.7 9.3 15.0 10.2
81
7.6 6.0 8.7 7.3 9.8 7. 6 10.4 8.7 12.0 8.5 12.6 8.9 14.6 9.2 14.7 10.1
86
7.6 6.0 8.7 7.3 9.8 7. 6 10.4 8.7 12.0 8.5 12.6 8.9 14.3 9.1 14.4 10.0
91
7.6 6.0 8.7 7.3 9.8 7. 6 10.4 8.7 12.0 8.5 12.6 8.9 14.0 9.0 14.1 9.9
95
7.6 6.0 8.7 7.3 9.8 7. 6 10.4 8.7 12.0 8.5 12.6 8.9 13.7 8.9 13.9 9.8
99
7.6 6.0 8.7 7.3 9.8 7. 6 10.4 8.7 12.0 8.5 12.6 8.9 13.5 8.8 13.6 9.7
104
7.6 6.0 8.7 7.3 9.8 7. 6 10.4 8.7 12.0 8.5 12.6 8.9 13.2 8.7 13.3 9.6
109
7.6 6.0 8.7 7.3 9.8 7. 6 10.4 8.7 12.0 8.5 12.3 8.8 12.8 8.6 13.0 9.5
115
7.6 6.0 8.7 7.3 9.8 7. 6 10.4 8.7 11.8 8.4 11.9 8.7 12.5 8.4 12.6 9.3
Outdoor
temperature
Indoor temperature
68°FDB / 59 °FWB 73°FDB / 61 °FWB 75°FDB / 63 °FWB 79°FDB / 64 °FWB 80°FDB / 67 °FWB 82°FDB / 68 °FWB 86°FDB / 72 °FWB 90°FDB / 73 °FWB
(°FDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
50
6.0 4.7 6.9 5.7 7.8 5.9 8.2 6.8 9.5 6.6 9.9 6.9 11.7 7. 2 12.1 8.0
59
6.0 4.7 6.9 5.7 7.8 5.9 8.2 6.8 9.5 6.6 9.9 6.9 11.7 7. 2 12.1 8.0
70
6.0 4.7 6.9 5.7 7.8 5.9 8.2 6.8 9.5 6.6 9.9 6.9 11.7 7. 2 12.1 8.0
73
6.0 4.7 6.9 5.7 7.8 5.9 8.2 6.8 9.5 6.6 9.9 6.9 11.7 7. 2 12.1 8.0
77
6.0 4.7 6.9 5.7 7.8 5.9 8.2 6.8 9.5 6.6 9.9 6.9 11.7 7. 2 11.9 7. 9
81
6.0 4.7 6.9 5.7 7.8 5.9 8.2 6.8 9.5 6.6 9.9 6.9 11.5 7. 2 11.7 7.8
86
6.0 4.7 6.9 5.7 7.8 5.9 8.2 6.8 9.5 6.6 9.9 6.9 11.3 7.1 11.4 7.7
91
6.0 4.7 6.9 5.7 7.8 5.9 8.2 6.8 9.5 6.6 9.9 6.9 11.1 7.0 11.2 7.6
95
6.0 4.7 6.9 5.7 7.8 5.9 8.2 6.8 9.5 6.6 9.9 6.9 10.9 6.9 11.0 7. 6
99
6.0 4.7 6.9 5.7 7.8 5.9 8.2 6.8 9.5 6.6 9.9 6.9 10.7 6.8 10.8 7. 5
104
6.0 4.7 6.9 5.7 7.8 5.9 8.2 6.8 9.5 6.6 9.9 6.9 10.4 6.7 10.5 7. 4
109
6.0 4.7 6.9 5.7 7.8 5.9 8.2 6.8 9.5 6.6 9.7 6.8 10.2 6.7 10.3 7. 3
115
6.0 4.7 6.9 5.7 7.8 5.9 8.2 6.8 9.3 6.5 9.4 6.7 9.9 6.5 10.0 7.2
Outdoor
temperature
Indoor temperature
68°FDB / 59 °FWB 73°FDB / 61 °FWB 75°FDB / 63 °FWB 79°FDB / 64 °FWB 80°FDB / 67 °FWB 82°FDB / 68 °FWB 86°FDB / 72 °FWB 90°FDB / 73 °FWB
(°FDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
50
4.8 4.1 5.4 5.0 6.1 5.2 6.5 6.0 7.5 5.7 7. 8 6.0 9.2 6.3 9.6 7.0
59
4.8 4.1 5.4 5.0 6.1 5.2 6.5 6.0 7.5 5.7 7. 8 6.0 9.2 6.3 9.6 7.0
70
4.8 4.1 5.4 5.0 6.1 5.2 6.5 6.0 7.5 5.7 7. 8 6.0 9.2 6.3 9.6 7.0
73
4.8 4.1 5.4 5.0 6.1 5.2 6.5 6.0 7.5 5.7 7. 8 6.0 9.2 6.3 9.5 7.0
77
4.8 4.1 5.4 5.0 6.1 5.2 6.5 6.0 7.5 5.7 7. 8 6.0 9.2 6.3 9.4 6.9
81
4.8 4.1 5.4 5.0 6.1 5.2 6.5 6.0 7.5 5.7 7. 8 6.0 9.1 6.2 9.2 6.9
86
4.8 4.1 5.4 5.0 6.1 5.2 6.5 6.0 7.5 5.7 7. 8 6.0 8.9 6.1 9.0 6.8
91
4.8 4.1 5.4 5.0 6.1 5.2 6.5 6.0 7.5 5.7 7. 8 6.0 8.7 6.1 8.8 6.7
95
4.8 4.1 5.4 5.0 6.1 5.2 6.5 6.0 7.5 5.7 7. 8 6.0 8.6 6.0 8.7 6.7
99
4.8 4.1 5.4 5.0 6.1 5.2 6.5 6.0 7.5 5.7 7. 8 6.0 8.4 6.0 8.5 6.6
104
4.8 4.1 5.4 5.0 6.1 5.2 6.5 6.0 7.5 5.7 7. 8 6.0 8.2 5.9 8.3 6.6
109
4.8 4.1 5.4 5.0 6.1 5.2 6.5 6.0 7.5 5.7 7.7 6.0 8.0 5.8 8.1 6.5
115
4.8 4.1 5.4 5.0 6.1 5.2 6.5 6.0 7.4 5.7 7. 5 5.9 7.8 5.7 7. 9 6.4
Outdoor
temperature
Indoor temperature
68°FDB / 59 °FWB 73°FDB / 61 °FWB 75°FDB / 63 °FWB 79°FDB / 64 °FWB 80°FDB / 67 °FWB 82°FDB / 68 °FWB 86°FDB / 72 °FWB 90°FDB / 73 °FWB
(°FDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
50
2.5 2 .1 2.9 2.6 3.3 2.7 3.5 3.1 4.0 3.0 4.2 3.1 4.9 3.3 5.1 3.6
59
2.5 2 .1 2.9 2.6 3.3 2.7 3.5 3.1 4.0 3.0 4.2 3.1 4.9 3.3 5.1 3.6
70
2.5 2 .1 2.9 2.6 3.3 2.7 3.5 3.1 4.0 3.0 4.2 3.1 4.9 3.3 5.1 3.6
73
2.5 2 .1 2.9 2.6 3.3 2.7 3.5 3.1 4.0 3.0 4.2 3.1 4.9 3.3 5.1 3.6
77
2.5 2 .1 2.9 2.6 3.3 2.7 3.5 3.1 4.0 3.0 4.2 3.1 4.9 3.3 5.0 3.6
81
2.5 2 .1 2.9 2.6 3.3 2.7 3.5 3.1 4.0 3.0 4.2 3.1 4.9 3.2 4.9 3.6
86
2.5 2 .1 2.9 2.6 3.3 2.7 3.5 3.1 4.0 3.0 4.2 3.1 4.8 3.2 4.8 3.5
91
2.5 2 .1 2.9 2.6 3.3 2.7 3.5 3.1 4.0 3.0 4.2 3.1 4.7 3.2 4.7 3.5
95
2.5 2 .1 2.9 2.6 3.3 2.7 3.5 3.1 4.0 3.0 4.2 3.1 4.6 3.1 4.6 3.5
99
2.5 2 .1 2.9 2.6 3.3 2.7 3.5 3.1 4.0 3.0 4.2 3.1 4.5 3 .1 4.5 3.4
104
2.5 2 .1 2.9 2.6 3.3 2.7 3.5 3.1 4.0 3.0 4.2 3.1 4.4 3.1 4.4 3.4
109
2.5 2 .1 2.9 2.6 3.3 2.7 3.5 3.1 4.0 3.0 4.1 3 .1 4.3 3.0 4.3 3.4
115
2.5 2 .1 2.9 2.6 3.3 2.7 3.5 3.1 3.9 3.0 4.0 3.1 4.2 3.0 4.2 3.3
