HEATING CAPACITY
TC : Total Capacity kBtu/h.
IP : Input Power kW (Compressor + Outdoor fan motor).
The data is based on the following conditions. Pipe length : 25 ft. (7.5 m) , Height di󰀨erence : 0 ft. (0 m).
5. CAPACITY TABLE HEATING (OUTDOOR UNIT)

MODEL : AOU36RLAVM
z
Capacity : 42 kBtu/h (3 ton)
Total rated
cooling capacity
of indoor unit
Outdoor temperature
Indoor temperature
61°FDB 64°FDB 68°FDB 70°FDB 72°FDB 75°FDB 79°FDB
(°FDB)
(°FWB) TC IP TC IP TC IP TC IP TC IP TC IP TC IP
54.6
(130%)
-4.0
-5.3
33.6 3.12 33.6 3.21 33.6 3.33 33.6 3.38 33.6 3.44 33.6 3.53 33.6 3.65
5.0
3.2
38.2 3.31 38.1 3.41 3 8.1 3.54 38.0 3.61 38.0 3.68 38.0 3.78 37.9 3.92
10.4
8.6
40.9 3.45 40.8 3.56 40.7 3.71 40.7 3.78 40.6 3.85 40.5 3.96 40.4 4.10
15.8
14.0
44.5 3.55 44.4 3.66 44.3 3.81 44.2 3.89 44.1 3.96 44.0 4.07 43.9 4.22
17. 0
15.0
46.0 3.55 45.9 3.66 45.7 3.81 45.6 3.89 45.6 3.96 45.4 4.07 45.2 4.22
23.0
21.2
48.1 3.69 48.0 3.80 47.8 3.95 47.7 4.03 47.6 4.11 47. 5 4.22 45.2 4.38
26.6
24.8
49.5 3.74 49.3 3.86 4 9.1 4.01 49.0 4.09 48.9 4.16 48.7 4.28 45.2 4.15
30.2
28.4
51.3 3.83 51.1 3.95 50.9 4.10 50.8 4.18 50.7 4.26 49.4 4.35 45.2 3.96
32.0
30.2
51.9 3.90 51.8 4.02 51.5 4.17 51.4 4.25 51.3 4.33 49.4 4.27 45.2 3.88
35.6
33.8
53.7 4.04 53.6 4.15 53.3 4.31 53.2 4.39 52.5 4.39 49.4 4.11 45.2 3.73
41.0
39.2
57.3 4.25 5 7.1 4.37 56.7 4.51 54.6 4.32 52.5 4.14 49.4 3.87 45.2 3.52
47.0
43.0
59.9 4.40 59.7 4.52 56.7 4.33 54.6 4.15 52.5 3.98 49.4 3.72 45.2 3.38
48.2
46.0
62.0 4.52 60.9 4.53 56.7 4.19 54.6 4.02 52.5 3.85 49.4 3.60 45.2 3.27
53.6
51.1
64.1 4.54 60.9 4.29 56.7 3.96 54.6 3.80 52.5 3.64 49.4 3.40 45.2 3.09
59.0
56.3
64.1 4.29 60.9 4.05 56.7 3.74 54.6 3.59 52.5 3.44 49.4 3.22 45.2 2.92
50.4
(120%)
-4.0
-5.3
33.6 3.19 33.6 3.28 33.6 3.40 33.6 3.46 33.6 3.52 33.6 3.61 33.6 3.73
5.0
3.2
38.1 3.40 3 8.1 3.50 38.0 3.64 38.0 3.71 38.0 3.77 37. 9 3.88 37. 8 4.01
10.4
8.6
40.8 3.56 40.7 3.67 40.6 3.82 40.6 3.89 40.5 3.96 40.4 4.07 40.3 4.21
15.8
14.0
44.4 3.67 44.3 3.79 4 4.1 3.93 4 4.1 4.01 44.0 4.08 43.9 4.20 41.7 4.35
17. 0
15.0
45.8 3.67 45.7 3.79 45.6 3.93 45.5 4.01 45.4 4.08 45.3 4.20 41.7 4.35
23.0
21.2
48.0 3.83 47.8 3.94 47.6 4.09 47.5 4.17 47. 4 4.24 45.6 4.36 41.7 4.04
26.6
24.8
49.3 3.89 49.1 4.00 48.9 4.15 48.8 4.23 48.5 4.31 45.6 4.19 41.7 3.81
30.2
28.4
51.1 3.99 50.9 4.10 50.7 4.25 50.4 4.33 48.5 4.27 45.6 3.99 41.7 3.64
32.0
30.2
51.7 4.06 51.5 4.17 51.3 4.33 50.4 4.37 48.5 4.19 45.6 3.92 41.7 3.57
35.6
33.8
53.5 4.20 53.3 4.32 52.3 4.38 50.4 4.20 48.5 4.03 45.6 3.77 41.7 3.43
41.0
39.2
57.0 4.43 56.2 4.46 52.3 4.13 50.4 3.96 48.5 3.80 45.6 3.56 41.7 3.24
47.0
43.0
59.1 4.53 56.2 4.28 52.3 3.96 50.4 3.80 48.5 3.65 45.6 3.41 41.7 3 .10
48.2
46.0
59.1 4.38 56.2 4 .15 52.3 3.84 50.4 3.68 48.5 3.53 45.6 3.30 41.7 3.00
53.6
51.1
59.1 4.15 56.2 3.92 52.3 3.63 50.4 3.48 48.5 3.34 45.6 3 .12 41.7 2.84
59.0
56.3
59.1 3.92 56.2 3.71 52.3 3.43 50.4 3.29 48.5 3.15 45.6 2.95 41.7 2.69
46.2
(110%)
-4.0
-5.3
33.6 3.28 33.6 3.37 33.6 3.49 33.6 3.55 33.6 3.61 33.6 3.70 33.6 3.82
5.0
3.2
38.1 3.51 38.0 3.62 38.0 3.75 37.9 3.82 37.9 3.89 37. 9 3.99 37. 8 4.13
10.4
8.6
40.7 3.69 40.6 3.80 40.5 3.94 40.5 4.02 40.4 4.09 40.3 4.20 38.2 4.34
15.8
14.0
44.3 3.82 44.2 3.93 44.0 4.08 43.9 4.15 43.9 4.23 41.8 4.34 38.2 4.08
17. 0
15.0
45.7 3.82 45.6 3.93 45.4 4.08 45.4 4.15 44.4 4.23 41.8 4.34 38.2 4.01
23.0
21.2
47.8 3.99 47.6 4 .10 47. 4 4.25 46.2 4.33 44.4 4.32 41.8 4.05 38.2 3.69
26.6
24.8
49.0 4.06 48.9 4.17 48.0 4.32 46.2 4.25 44.4 4.08 41.8 3.82 38.2 3.48
30.2
28.4
50.8 4.17 50.6 4.28 48.0 4.22 46.2 4.06 44.4 3.89 41.8 3.64 38.2 3.32
32.0
30.2
51.4 4.24 51.2 4.36 48.0 4 .14 46.2 3.98 44.4 3.82 41.8 3.57 38.2 3.26
35.6
33.8
53.2 4.40 51.5 4.30 48.0 3.98 46.2 3.83 44.4 3.67 41.8 3.44 38.2 3.13
41.0
39.2
54.2 4.29 51.5 4.06 48.0 3.76 46.2 3.61 44.4 3.46 41.8 3.24 38.2 2.95
47.0
43.0
54.2 4.12 51.5 3.90 48.0 3.61 46.2 3.46 44.4 3.32 41.8 3.11 38.2 2.83
48.2
46.0
54.2 3.98 51.5 3.77 48.0 3.49 46.2 3.35 44.4 3.21 41.8 3.01 38.2 2.74
53.6
51.1
54.2 3.77 51.5 3.57 48.0 3.30 46.2 3.17 44.4 3.04 41.8 2.85 38.2 2.60
59.0
56.3
54.2 3.56 51.5 3.37 48.0 3 .12 46.2 3.00 44.4 2.87 41.8 2.69 38.2 2.45
42.0
(100%)
-4.0
-5.3
33.6 3.38 33.6 3.47 33.6 3.59 33.6 3.65 33.6 3.71 33.6 3.81 33.6 3.93
5.0
3.2
38.0 3.65 38.0 3.75 37.9 3.89 37.9 3.96 37. 8 4.02 37. 8 4.13 34.7 4.18
10.4
8.6
40.6 3.85 40.5 3.96 40.4 4.10 40.4 4.17 40.3 4.24 38.0 4.35 34.7 3.98
15.8
14.0
44.1 3.99 44.0 4.10 43.6 4.25 42.0 4.32 40.4 4.33 38.0 4.06 34.7 3.70
17. 0
15.0
45.5 3.99 45.4 4.11 43.6 4.25 42.0 4.33 40.4 4.24 38.0 3.98 34.7 3.63
23.0
21.2
47.5 4.18 46.8 4.29 43.6 4.24 42.0 4.07 40.4 3.91 38.0 3.66 34.7 3.34
26.6
24.8
48.8 4.26 46.8 4.32 43.6 4.00 42.0 3.85 40.4 3.69 38.0 3.46 34.7 3 .15
30.2
28.4
49.3 4.34 46.8 4.12 43.6 3.81 42.0 3.67 40.4 3.52 38.0 3.30 34.7 3.01
32.0
30.2
49.3 4.26 46.8 4.04 43.6 3.74 42.0 3.60 40.4 3.45 38.0 3.23 34.7 2.95
35.6
33.8
49.3 4.10 46.8 3.88 43.6 3.60 42.0 3.46 40.4 3.32 38.0 3 .11 34.7 2.84
41.0
39.2
49.3 3.87 46.8 3.66 43.6 3.39 42.0 3.26 40.4 3.13 38.0 2.93 34.7 2.68
47.0
43.0
49.3 3.71 46.8 3.52 43.6 3.26 42.0 3.13 40.4 3.00 38.0 2.82 34.7 2.57
48.2
46.0
49.3 3.59 46.8 3.40 43.6 3 .15 42.0 3.03 40.4 2.91 38.0 2.72 34.7 2.49
53.6
51.1
49.3 3.40 46.8 3.22 43.6 2.98 42.0 2.87 40.4 2.75 38.0 2.58 34.7 2.35
59.0
56.3
49.3 3.21 46.8 3.04 43.6 2.82 42.0 2.71 40.4 2.60 38.0 2.44 34.7 2.22
37.8
(90%)
-4.0
-5.3
33.6 3.51 33.6 3.60 33.6 3.72 33.6 3.78 33.6 3.85 33.6 3.94 31.3 4.03
5.0
3.2
37.9 3.81 37.9 3.92 37. 8 4.05 37. 8 4.12 36.4 4.19 34.2 4.11 31.3 3.75
10.4
8.6
40.5 4.04 40.4 4.14 39.3 4.29 37.8 4.34 36.4 4 .17 34.2 3.91 31.3 3.57
15.8
14.0
43.9 4.20 42.2 4.31 39.3 4.20 37.8 4.04 36.4 3.88 34.2 3.64 31.3 3.32
17. 0
15.0
44.3 4.21 42.2 4.32 39.3 4 .12 37. 8 3.96 36.4 3.80 34.2 3.57 31.3 3.26
23.0
21.2
44.3 4.31 42.2 4.09 39.3 3.79 3 7. 8 3.65 36.4 3.50 34.2 3.29 31.3 3.00
26.6
24.8
44.3 4.07 42.2 3.86 39.3 3.58 3 7.8 3.44 36.4 3.31 34.2 3.10 31.3 2.83
30.2
28.4
44.3 3.88 42.2 3.68 39.3 3.41 37.8 3.28 36.4 3 .15 34.2 2.96 31.3 2.70
32.0
30.2
44.3 3.81 42.2 3.61 39.3 3.35 37. 8 3.22 36.4 3.09 34.2 2.90 31.3 2.65
35.6
33.8
44.3 3.66 42.2 3.47 39.3 3.22 37. 8 3.10 36.4 2.97 34.2 2.79 31.3 2.55
41.0
39.2
44.3 3.45 42.2 3.27 39.3 3.04 3 7.8 2.92 36.4 2.80 34.2 2.63 31.3 2.40
47.0
43.0
44.3 3.32 42.2 3 .14 39.3 2.92 37. 8 2.80 36.4 2.69 34.2 2.52 31.3 2.31
48.2
46.0
44.3 3.21 42.2 3.04 39.3 2.82 37. 8 2.71 36.4 2.60 34.2 2.44 31.3 2.23
53.6
51.1
44.3 3.04 42.2 2.88 39.3 2.67 3 7.8 2.57 36.4 2.47 34.2 2.31 31.3 2 .11
59.0
56.3
44.3 2.87 42.2 2.72 39.3 2.52 37.8 2.43 36.4 2.33 34.2 2 .19 31.3 2.00
