Note : Specications are based on the following conditions.
Cooling : Indoor temperature of 80°F(26.7°C)DB/67°F(19.4°C)WB,and outdoor temperature of 95.0°F(35°C)DB/75°F(23.9°C)WB.
Heating : Indoor temperature of 70°F(21.1°C)DB/60°F(15.6°C)WB,and outdoor temperature of 47°F(8.3°C)DB/43°F(6.1°C)WB.
Pipe length : 25ft.(7.5 m), Height difference : 0ft.(0 m) (Outdoor unit - Indoor unit).
The protective function might work when using it outside the operation range.
1-7. HIGH STATIC PRESSURE DUCT TYPE
Model name ARUH36TLAV ARUH48TLAV ARUH60TLAV
Power source 1 Phase ~ 208/230V 60Hz
Available voltage range 187 to 253 V
Capacity
Cooling
Btu/h 36,000 48,000 60,000
kW 10.6 14.1 17.6
Heating
Btu/h 40,000 54,000 67,000
kW 11.7 15.8 19.6
Input power W 496 752 806
Static pressure range in.WG(Pa)
0.40 to 0.80
(100 to 200)
0.40 to 1.00 (100 to 250)
Standard static pressure in.WG(Pa) 0.40 (100)
Fan
Airow
rate
High
CFM
(m
3
/ h)
1,324
(2,250)
1,766
(3,000)
1,972
(3,350)
Med
1,030
(1,750)
1,589
(2,700)
1,678
(2,850)
Low
824
(1,400)
1,354
(2,300)
1,501
(2,550)
Type x Quantity Sirocco × 2
Motor output W 247 424 482
Sound pressure
level
High
dB(A)
43 47 48
Med 37 43 44
Low 32 40 41
Heat exchanger
Length in. (mm) 35-1/16 (890)
Fin pitch FPI 19 17
Rows x Stages 4 × 16
Face Area ft
2
. (m
2
) 3.2 (0.30)
Pipe type (Material) Grooved H-pin (Copper)
Fin
Type (Material) Slit(Aluminum)
Surface
treatment
Hydrophilic coating
Air lter (Option)
Model name UTD-LF60KA
Type Fungicide type
Net material PP honeycomb
Enclosure
Material Galvanized sheet iron
Color -
Dimensions
(H x W x D)
Net
in. (mm)
15-3/4 × 41-5/16 × 19-11/16 (400 × 1,050 × 500)
Gross 18-1/8 × 48-7/16 × 25-3/16 (460 × 1,230 × 640)
Weight
Net
lbs. (kg)
97 (44) 101 (46)
Gross 108 (49) 112 (51)
Connection
pipe diameter
Liquid (Flare)
in. (mm)
ø 3/8 (9.52)
Gas (Flare) ø 3/4 (19.05)
Drain hose ø3/4 (19.05) [I.D.]; ø1-1/16 (26.6) [O.D.]
- (04-10) -
