Note : Specications are based on the following conditions.
Cooling : Indoor temperature of 80°F(26.7°C)DB/67°F(19.4°C)WB,and outdoor temperature of 95.0°F(35°C)DB/75°F(23.9°C)WB.
Heating : Indoor temperature of 70°F(21.1°C)DB/60°F(15.6°C)WB,and outdoor temperature of 47°F(8.3°C)DB/43°F(6.1°C)WB.
Pipe length : 25ft.(7.5 m), Height difference : 0ft.(0 m) (Outdoor unit - Indoor unit).
The protective function might work when using it outside the operation range.
1-9. COMPACT FLOOR TYPE
Model name
AGUA4TLAV1 AGUA7TLAV1 AGUA9TLAV1 AGUA12TLAV1 AGUA14TL AV1
Power source 1 Phase ~ 208/230V 60Hz
Available voltage range 187 to 253 V
Capacity
Cooling
Btu/h 4,000 7,5 0 0 9,500 12,000 14,000
kW 1.2 2.2 2.8 3.5 4.1
Heating
Btu/h 4,400 9,500 10,900 13,500 15,600
kW 1.3 2.8 3.2 4.0 4.6
Input power W
12/14 16 17 22 29
Fan
Airow
rate
High
CFM
(m
3
/ h)
224/253
(380/430)
277
(470)
294
(500)
347
(590)
394
(670)
Med-Hi
206
(350)
247
(420)
265
(450)
306
(520)
347
(590)
Med
188
(320)
230
(390)
235
(400)
277
(470)
306
(520)
Low-Hi
182
(310)
212
(360)
212
(360)
247
(420)
265
(450)
Low
165
(280)
194
(330)
194
(330)
230
(390)
230
(390)
Quiet
124
(210)
159
(270)
159
(270)
200
(340)
200
(340)
Type x Quantity Cross ow × 2
Motor output W 16 × 2
Sound pressure
level
High
dB(A)
35/36 37 38 42 46
Med-Hi
33 35 36 39 42
Med
31 33 34 37 39
Low-Hi
30 31 31 35 36
Low
28 29 29 33 33
Quiet
22 22 22 30 30
Heat exchanger
Length in. (mm) 21-5/8 (550)
Fin pitch FPI 21
Rows x Stages 2 × 18
Face Area ft
2
. (m
2
) 2.3 (0.21)
Pipe type (Material) Grooved H-pin (Copper)
Fin
Type (Material) Slit (Aluminum)
Surface treatment Hydrophilic coating
Air lter
Type Anti mold
Net material PP plain weave
Enclosure
Material Plastic
Color
White
Approximate color of MUNSELL 5Y 9/0.5NN
Dimensions
(H x W x D)
Net
in. (mm)
23-5/8 × 29-1/8 × 7-7/8 (600 × 740 × 200)
Gross 27-9/16 × 32-5/16 × 12-3/16 (700 × 820 × 310)
Weight
Net
lbs. (kg)
33 (15)
Gross
41 (18.5)
42 (19)
Connection
pipe diameter
Liquid (Flare)
in. (mm)
ø 1/4 (6.35)
Gas (Flare) ø 3/8 (9.52) ø 1/2 (12.70)
Drain hose ø9/16 (13.8) [I.D.]; ø5/8 (15.8) to 11/16 (16.7) [O.D.]
