Fujitsu Airstage J-II Series User Manual

Note : Specications are based on the following conditions.
Cooling : Indoor temperature of 80°F(26.7°C)DB/67°F(19.4°C)WB,and outdoor temperature of 95.0°F(35°C)DB/75°F(23.9°C)WB.
Heating : Indoor temperature of 70°F(21.1°C)DB/60°F(15.6°C)WB,and outdoor temperature of 47°F(8.3°C)DB/43°F(6.1°C)WB.
Pipe length : 25ft.(7.5 m), Height difference : 0ft.(0 m) (Outdoor unit - Indoor unit).
The protective function might work when using it outside the operation range.
Model name ARUV30TLAV ARUV36TLAV ARUV48TLAV ARUV60TLAV
Power source 1 Phase ~ 208/230V 60Hz
Available voltage range 187 to 253 V
Capacity
Cooling
Btu/h 30,000 36,000 48,000 60,000
kW 8.8 10.6 14.1 17.6
Heating
Btu/h 34,000 40,000 54,000 67,000
kW 10.0 11.7 15.8 19.6
Input power W 253 427 479 785
Static pressure range in.WG(Pa) 0.10 to 0.80 (25 to 200)
Standard static pressure in.WG(Pa) 0.50 (125)
Fan
Airow
rate
High
CFM
(m
3
/ h)
1,092 (1,855) 1,372 (2,331) 1,531 (2,602) 2,013 (3,420)
Med 942 (1,600) 1,271 (2,160) 1,407 (2,390) 1,883 (3,200)
Low 818 (1,390) 954 (1,620) 1,130 (1,920) 1,542 (2,620)
Type x Quantity Sirocco × 1
Motor output W 373 373 560 746
Sound pressure
level
High
dB(A)
45 48 48 53
Med 43 46 46 50
Low 40 40 41 45
Heat exchanger
Length in. (mm) 18 (457)
Fin pitch FPI 10
Rows x Stages (3 × 12) × 2 (4 × 12) × 2 (3 × 20) × 2 (4 × 20) × 2
Face Area ft
2
. (m
2
) 3.0 (0.28) 3.0 (0.28) 5.0 (0.46) 5.0 (0.46)
Pipe type (Material) Grooved H-pin (Copper)
Fin Type (Material) Slit (Aluminum)
Air lter (Locally
purchased)
Type MERV3
Size in. (mm) 20 × 22-1/4 × 1 (508 × 565 × 25.4)
22
×
22
×
1
(559 × 559 × 25.4)
Enclosure
Material Painted galvanized steel
Color Gray
Dimensions
(H x W x D)
Net
in. (mm)
51 × 22-3/16 × 23-13/16
(1,295 × 564 × 605)
57-1/2 × 25-1/8 × 23-13/16
(1,461 × 638 × 605)
Gross 58-1/2 × 28 × 33 (1,486 × 711 × 838) 65 × 28 × 33 (1,651 × 711 × 838)
Weight
Net
lbs. (kg)
174 (79) 179 (81) 212 (96) 223 (101)
Gross 208 (95) 213 (97) 247 (113) 258 (118)
Connection
pipe diameter
Liquid (Flare)
in. (mm)
ø 3/8 (9.52)
Gas (Flare) ø 5/8 (15.88) ø 3/4 (19.05)
Drain hose ø 3/4 (19.05) [I.D.]
- (04-13) -
