Fujitsu Airstage J-II Series User Manual

TC : Total Capacity kBtu/h.
SHC : Sensible Heat Capacity kBtu/h.
COOLING CAPACITY
in kBtu/h
Outdoor
temperature
Indoor temperature
68°FDB / 59 °FWB 73°FDB / 61 °FWB 75°FDB / 63 °FWB 79°FDB / 64 °FWB 80°FDB / 67 °FWB 82°FDB / 68 °FWB 86°FDB / 72 °FWB 90°FDB / 73 °FWB
(°FDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
50
6.0 5.5 6.9 6.8 7.8 7. 0 8.2 8.2 9.5 7.8 9.9 8.2 11.7 8.4 12.1 9.5
59
6.0 5.5 6.9 6.8 7.8 7. 0 8.2 8.2 9.5 7.8 9.9 8.2 11.7 8.4 12.1 9.5
70
6.0 5.5 6.9 6.8 7.8 7. 0 8.2 8.2 9.5 7.8 9.9 8.2 11.7 8.4 12.1 9.5
73
6.0 5.5 6.9 6.8 7.8 7. 0 8.2 8.2 9.5 7.8 9.9 8.2 11.7 8.4 12.1 9.5
77
6.0 5.5 6.9 6.8 7.8 7. 0 8.2 8.2 9.5 7.8 9.9 8.2 11.7 8.4 11.9 9.4
81
6.0 5.5 6.9 6.8 7.8 7. 0 8.2 8.2 9.5 7.8 9.9 8.2 11.5 8.4 11.7 9.3
86
6.0 5.5 6.9 6.8 7.8 7. 0 8.2 8.2 9.5 7.8 9.9 8.2 11.3 8.3 11.4 9.2
91
6.0 5.5 6.9 6.8 7.8 7. 0 8.2 8.2 9.5 7.8 9.9 8.2 11.1 8.2 11.2 9.2
95
6.0 5.5 6.9 6.8 7.8 7. 0 8.2 8.2 9.5 7.8 9.9 8.2 10.9 8.2 11.0 9.1
99
6.0 5.5 6.9 6.8 7.8 7. 0 8.2 8.2 9.5 7.8 9.9 8.2 10.7 8.1 10.8 9.0
104
6.0 5.5 6.9 6.8 7.8 7. 0 8.2 8.2 9.5 7.8 9.9 8.2 10.4 8.0 10.5 8.9
109
6.0 5.5 6.9 6.8 7.8 7. 0 8.2 8.2 9.5 7.8 9.7 8 .1 10.2 7.9 10.3 8.9
115
6.0 5.5 6.9 6.8 7.8 7. 0 8.2 8.2 9.3 7.7 9.4 8.0 9.9 7.8 10.0 8.8
Outdoor
temperature
Indoor temperature
68°FDB / 59 °FWB 73°FDB / 61 °FWB 75°FDB / 63 °FWB 79°FDB / 64 °FWB 80°FDB / 67 °FWB 82°FDB / 68 °FWB 86°FDB / 72 °FWB 90°FDB / 73 °FWB
(°FDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
50
4.8 4.1 5.4 5.0 6.1 5.2 6.5 6.0 7. 5 5.7 7.8 6.0 9.2 6.3 9.6 7.0
59
4.8 4.1 5.4 5.0 6.1 5.2 6.5 6.0 7. 5 5.7 7.8 6.0 9.2 6.3 9.6 7.0
70
4.8 4.1 5.4 5.0 6.1 5.2 6.5 6.0 7. 5 5.7 7.8 6.0 9.2 6.3 9.6 7.0
73
4.8 4.1 5.4 5.0 6.1 5.2 6.5 6.0 7. 5 5.7 7.8 6.0 9.2 6.3 9.5 7.0
77
4.8 4.1 5.4 5.0 6.1 5.2 6.5 6.0 7. 5 5.7 7.8 6.0 9.2 6.3 9.4 6.9
81
4.8 4.1 5.4 5.0 6.1 5.2 6.5 6.0 7. 5 5.7 7.8 6.0 9.1 6.2 9.2 6.9
86
4.8 4.1 5.4 5.0 6.1 5.2 6.5 6.0 7. 5 5.7 7.8 6.0 8.9 6.2 9.0 6.8
91
4.8 4.1 5.4 5.0 6.1 5.2 6.5 6.0 7. 5 5.7 7.8 6.0 8.7 6.1 8.8 6.7
95
4.8 4.1 5.4 5.0 6.1 5.2 6.5 6.0 7. 5 5.7 7.8 6.0 8.6 6.0 8.7 6.7
99
4.8 4.1 5.4 5.0 6.1 5.2 6.5 6.0 7. 5 5.7 7.8 6.0 8.4 6.0 8.5 6.6
104
4.8 4.1 5.4 5.0 6.1 5.2 6.5 6.0 7. 5 5.7 7.8 6.0 8.2 5.9 8.3 6.6
109
4.8 4.1 5.4 5.0 6.1 5.2 6.5 6.0 7. 5 5.7 7.7 6.0 8.0 5.8 8.1 6.5
115
4.8 4.1 5.4 5.0 6.1 5.2 6.5 6.0 7. 4 5.7 7.5 5.9 7.8 5.8 7.9 6.4
Outdoor
temperature
Indoor temperature
68°FDB / 59 °FWB 73°FDB / 61 °FWB 75°FDB / 63 °FWB 79°FDB / 64 °FWB 80°FDB / 67 °FWB 82°FDB / 68 °FWB 86°FDB / 72 °FWB 90°FDB / 73 °FWB
(°FDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
50
2.5 2.0 2.9 2.4 3.3 2.5 3.5 2.9 4.0 2.8 4.2 2.9 4.9 3.1 5.1 3.4
59
2.5 2.0 2.9 2.4 3.3 2.5 3.5 2.9 4.0 2.8 4.2 2.9 4.9 3.1 5.1 3.4
70
2.5 2.0 2.9 2.4 3.3 2.5 3.5 2.9 4.0 2.8 4.2 2.9 4.9 3.1 5.1 3.4
73
2.5 2.0 2.9 2.4 3.3 2.5 3.5 2.9 4.0 2.8 4.2 2.9 4.9 3.1 5.1 3.4
77
2.5 2.0 2.9 2.4 3.3 2.5 3.5 2.9 4.0 2.8 4.2 2.9 4.9 3.1 5.0 3.3
81
2.5 2.0 2.9 2.4 3.3 2.5 3.5 2.9 4.0 2.8 4.2 2.9 4.9 3.0 4.9 3.3
86
2.5 2.0 2.9 2.4 3.3 2.5 3.5 2.9 4.0 2.8 4.2 2.9 4.8 3.0 4.8 3.3
91
2.5 2.0 2.9 2.4 3.3 2.5 3.5 2.9 4.0 2.8 4.2 2.9 4.7 3.0 4.7 3.2
95
2.5 2.0 2.9 2.4 3.3 2.5 3.5 2.9 4.0 2.8 4.2 2.9 4.6 2.9 4.6 3.2
99
2.5 2.0 2.9 2.4 3.3 2.5 3.5 2.9 4.0 2.8 4.2 2.9 4.5 2.9 4.5 3.2
104
2.5 2.0 2.9 2.4 3.3 2.5 3.5 2.9 4.0 2.8 4.2 2.9 4.4 2.9 4.4 3.1
109
2.5 2.0 2.9 2.4 3.3 2.5 3.5 2.9 4.0 2.8 4.1 2.9 4.3 2.8 4.3 3 .1
115
2.5 2.0 2.9 2.4 3.3 2.5 3.5 2.9 3.9 2.8 4.0 2.8 4.2 2.8 4.2 3 .1
7-12. WALL MOUNTED TYPE

MODEL : ASUA4TLAV1

MODEL : ASUA7TLAV1

MODEL : ASUA9TLAV1
- (02 - 46) -
MODEL SELECTION MODEL SELECTION
