Fujitsu Airstage J-II Series User Manual

TC : Total Capacity kBtu/h.
SHC : Sensible Heat Capacity kBtu/h.
COOLING CAPACITY
in kBtu/h
7-7. HIGH STATIC PRESSURE DUCT TYPE

MODEL : ARUH36TLAV

MODEL : ARUH48TLAV

MODEL : ARUH60TLAV
Outdoor
temperature
Indoor temperature
68°FDB / 59 °FWB 73°FDB / 61 °FWB 75°FDB / 63 °FWB 79°FDB / 64 °FWB 80°FDB / 67 °FWB 82°FDB / 68 °FWB 86°FDB / 72 °FWB 90°FDB / 73 °FWB
(°FDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
50
38.1 31.6 43.5 38.6 49.0 40.0 51.8 46.0 60.0 44.3 62.8 46.6 73.7 48.4 76.5 53.9
59
38.1 31.6 43.5 38.6 49.0 40.0 51.8 46.0 60.0 44.3 62.8 46.6 73.7 48.4 76.5 53.9
70
38.1 31.6 43.5 38.6 49.0 40.0 51.8 46.0 60.0 44.3 62.8 46.6 73.7 48.4 76.5 53.9
73
38.1 31.6 43.5 38.6 49.0 40.0 51.8 46.0 60.0 44.3 62.8 46.6 73.7 48.4 76.1 53.8
77
38.1 31.6 43.5 38.6 49.0 40.0 51.8 46.0 60.0 44.3 62.8 46.6 73.7 48.4 74.9 53.3
81
38.1 31.6 43.5 38.6 49.0 40.0 51.8 46.0 60.0 44.3 62.8 46.6 72.9 48 .1 73.7 52.9
86
38.1 31.6 43.5 38.6 49.0 40.0 51.8 46.0 60.0 44.3 62.8 46.6 71.4 47.5 72.1 52.3
91
38.1 31.6 43.5 38.6 49.0 40.0 51.8 46.0 60.0 44.3 62.8 46.6 69.9 47.0 70.6 51.8
95
38.1 31.6 43.5 38.6 49.0 40.0 51.8 46.0 60.0 44.3 62.8 46.6 68.6 46.5 69.3 51.3
99
38.1 31.6 43.5 38.6 49.0 40.0 51.8 46.0 60.0 44.3 62.8 46.6 6 7. 4 4 6.1 68.1 50.9
104
38.1 31.6 43.5 38.6 49.0 40.0 51.8 46.0 60.0 44.3 62.8 46.6 65.8 45.5 66.5 50.4
109
38.1 31.6 43.5 38.6 49.0 40.0 51.8 46.0 60.0 44.3 61.5 4 6.1 64.2 44.9 64.9 49.8
115
38.1 31.6 43.5 38.6 49.0 40.0 51.8 46.0 59.0 43.9 59.6 45.3 62.3 44.2 62.9 49.1
Outdoor
temperature
Indoor temperature
68°FDB / 59 °FWB 73°FDB / 61 °FWB 75°FDB / 63 °FWB 79°FDB / 64 °FWB 80°FDB / 67 °FWB 82°FDB / 68 °FWB 86°FDB / 72 °FWB 90°FDB / 73 °FWB
(°FDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
50
30.4 24.2 34.8 29.4 39.2 30.6 41.4 35.0 48.0 33.9 50.2 35.7 59.0 37. 2 61.2 41.3
59
30.4 24.2 34.8 29.4 39.2 30.6 41.4 35.0 48.0 33.9 50.2 35.7 59.0 37. 2 61.2 41.3
70
30.4 24.2 34.8 29.4 39.2 30.6 41.4 35.0 48.0 33.9 50.2 35.7 59.0 37. 2 61.2 41.3
73
30.4 24.2 34.8 29.4 39.2 30.6 41.4 35.0 48.0 33.9 50.2 35.7 59.0 37. 2 60.9 41.1
77
30.4 24.2 34.8 29.4 39.2 30.6 41.4 35.0 48.0 33.9 50.2 35.7 59.0 37. 2 59.9 40.8
81
30.4 24.2 34.8 29.4 39.2 30.6 41.4 35.0 48.0 33.9 50.2 35.7 58.4 36.9 58.9 40.4
86
30.4 24.2 34.8 29.4 39.2 30.6 41.4 35.0 48.0 33.9 50.2 35.7 5 7.1 36.5 5 7.7 39.9
91
30.4 24.2 34.8 29.4 39.2 30.6 41.4 35.0 48.0 33.9 50.2 35.7 55.9 36.0 56.5 39.5
95
30.4 24.2 34.8 29.4 39.2 30.6 41.4 35.0 48.0 33.9 50.2 35.7 54.9 35.6 55.5 39.1
99
30.4 24.2 34.8 29.4 39.2 30.6 41.4 35.0 48.0 33.9 50.2 35.7 53.9 35.3 54.5 38.8
104
30.4 24.2 34.8 29.4 39.2 30.6 41.4 35.0 48.0 33.9 50.2 35.7 52.6 34.8 53.2 38.3
109
30.4 24.2 34.8 29.4 39.2 30.6 41.4 35.0 48.0 33.9 49.2 35.2 51.4 34.3 51.9 37. 8
115
30.4 24.2 34.8 29.4 39.2 30.6 41.4 35.0 47.2 33.6 47.7 34.6 49.8 33.8 50.4 37.3
Outdoor
temperature
Indoor temperature
68°FDB / 59 °FWB 73°FDB / 61 °FWB 75°FDB / 63 °FWB 79°FDB / 64 °FWB 80°FDB / 67 °FWB 82°FDB / 68 °FWB 86°FDB / 72 °FWB 90°FDB / 73 °FWB
(°FDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
50
22.8 18.1 26 .1 22.0 29.4 22.9 31.1 26.2 36.0 25.5 37.7 26.7 44.2 27. 9 45.9 30.9
59
22.8 18.1 26 .1 22.0 29.4 22.9 31.1 26.2 36.0 25.5 37.7 26.7 44.2 27. 9 45.9 30.9
70
22.8 18.1 26 .1 22.0 29.4 22.9 31.1 26.2 36.0 25.5 37.7 26.7 44.2 27. 9 45.9 30.9
73
22.8 18.1 26 .1 22.0 29.4 22.9 31.1 26.2 36.0 25.5 37.7 26.7 44.2 27. 9 45.7 30.9
77
22.8 18.1 26 .1 22.0 29.4 22.9 31.1 26.2 36.0 25.5 37.7 26.7 44.2 27. 9 44.9 30.6
81
22.8 18.1 26 .1 22.0 29.4 22.9 31.1 26.2 36.0 25.5 37.7 26.7 43.8 2 7.7 44.2 30.3
86
22.8 18.1 26 .1 22.0 29.4 22.9 31.1 26.2 36.0 25.5 37.7 26.7 42.8 27.4 43.3 30.0
91
22.8 18.1 26 .1 22.0 29.4 22.9 31.1 26.2 36.0 25.5 37.7 26.7 41.9 27.0 42.4 29.6
95
22.8 18.1 26 .1 22.0 29.4 22.9 31.1 26.2 36.0 25.5 37.7 26.7 41.2 26.7 41.6 29.3
99
22.8 18.1 26 .1 22.0 29.4 22.9 31.1 26.2 36.0 25.5 37.7 26.7 40.4 26.5 40.9 2 9.1
104
22.8 18.1 26 .1 22.0 29.4 22.9 31.1 26.2 36.0 25.5 37.7 26.7 39.5 26.1 39.9 28.7
109
22.8 18.1 26 .1 22.0 29.4 22.9 31.1 26.2 36.0 25.5 36.9 26.4 38.5 25.8 38.9 28.4
115
22.8 18.1 26 .1 22.0 29.4 22.9 31.1 26.2 35.4 25.2 35.8 26.0 37. 4 25.3 37. 8 28.0
