Fujitsu Airstage J-II Series User Manual

TC : Total Capacity kBtu/h.
SHC : Sensible Heat Capacity kBtu/h.
COOLING CAPACITY
in kBtu/h
7-5. SLIM DUCT / SLIM CONCEALED FLOOR TYPE

MODEL : ARUL7TLAV

MODEL : ARUL9TLAV

MODEL : ARUL12TLAV

MODEL : ARUL14TLAV
Outdoor
temperature
Indoor temperature
68°FDB / 59 °FWB 73°FDB / 61 °FWB 75°FDB / 63 °FWB 79°FDB / 64 °FWB 80°FDB / 67 °FWB 82°FDB / 68 °FWB 86°FDB / 72 °FWB 90°FDB / 73 °FWB
(°FDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
50
6.0 4.9 6.9 5.9 7.8 6.2 8.2 7.1 9.5 6.8 9.9 7.2 11.7 7. 5 12.1 8.3
59
6.0 4.9 6.9 5.9 7.8 6.2 8.2 7.1 9.5 6.8 9.9 7.2 11.7 7. 5 12.1 8.3
70
6.0 4.9 6.9 5.9 7.8 6.2 8.2 7.1 9.5 6.8 9.9 7.2 11.7 7. 5 12.1 8.3
73
6.0 4.9 6.9 5.9 7.8 6.2 8.2 7.1 9.5 6.8 9.9 7.2 11.7 7. 5 12.1 8.3
77
6.0 4.9 6.9 5.9 7.8 6.2 8.2 7.1 9.5 6.8 9.9 7.2 11.7 7. 5 11. 9 8.2
81
6.0 4.9 6.9 5.9 7.8 6.2 8.2 7.1 9.5 6.8 9.9 7.2 11. 5 7. 4 11.7 8.1
86
6.0 4.9 6.9 5.9 7.8 6.2 8.2 7.1 9.5 6.8 9.9 7.2 11. 3 7. 3 11.4 8.1
91
6.0 4.9 6.9 5.9 7.8 6.2 8.2 7.1 9.5 6.8 9.9 7.2 11.1 7. 2 11.2 8.0
95
6.0 4.9 6.9 5.9 7.8 6.2 8.2 7.1 9.5 6.8 9.9 7.2 10.9 7. 2 11.0 7. 9
99
6.0 4.9 6.9 5.9 7.8 6.2 8.2 7.1 9.5 6.8 9.9 7.2 10.7 7.1 10.8 7.8
104
6.0 4.9 6.9 5.9 7.8 6.2 8.2 7.1 9.5 6.8 9.9 7.2 10.4 7. 0 10.5 7.7
109
6.0 4.9 6.9 5.9 7.8 6.2 8.2 7.1 9.5 6.8 9.7 7.1 10.2 6.9 10.3 7. 6
115
6.0 4.9 6.9 5.9 7.8 6.2 8.2 7.1 9.3 6.8 9.4 7.0 9.9 6.8 10.0 7.5
Outdoor
temperature
Indoor temperature
68°FDB / 59 °FWB 73°FDB / 61 °FWB 75°FDB / 63 °FWB 79°FDB / 64 °FWB 80°FDB / 67 °FWB 82°FDB / 68 °FWB 86°FDB / 72 °FWB 90°FDB / 73 °FWB
(°FDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
50
4.8 4.1 5.4 5.1 6.1 5.2 6.5 6.0 7.5 5.8 7.8 6 .1 9.2 6.3 9.6 7.1
59
4.8 4.1 5.4 5.1 6.1 5.2 6.5 6.0 7.5 5.8 7.8 6 .1 9.2 6.3 9.6 7.1
70
4.8 4.1 5.4 5.1 6.1 5.2 6.5 6.0 7.5 5.8 7.8 6 .1 9.2 6.3 9.6 7.1
73
4.8 4.1 5.4 5.1 6.1 5.2 6.5 6.0 7.5 5.8 7.8 6 .1 9.2 6.3 9.5 7. 0
77
4.8 4.1 5.4 5.1 6.1 5.2 6.5 6.0 7.5 5.8 7.8 6 .1 9.2 6.3 9.4 7. 0
81
4.8 4.1 5.4 5.1 6.1 5.2 6.5 6.0 7.5 5.8 7.8 6 .1 9.1 6.3 9.2 6.9
86
4.8 4.1 5.4 5.1 6.1 5.2 6.5 6.0 7.5 5.8 7.8 6 .1 8.9 6.2 9.0 6.9
91
4.8 4.1 5.4 5.1 6.1 5.2 6.5 6.0 7.5 5.8 7.8 6 .1 8.7 6.1 8.8 6.8
95
4.8 4.1 5.4 5.1 6.1 5.2 6.5 6.0 7.5 5.8 7.8 6 .1 8.6 6.1 8.7 6.7
99
4.8 4.1 5.4 5.1 6.1 5.2 6.5 6.0 7.5 5.8 7.8 6 .1 8.4 6.0 8.5 6.7
104
4.8 4.1 5.4 5.1 6.1 5.2 6.5 6.0 7.5 5.8 7.8 6 .1 8.2 6.0 8.3 6.6
109
4.8 4.1 5.4 5.1 6.1 5.2 6.5 6.0 7.5 5.8 7.7 6.0 8.0 5.9 8.1 6.6
115
4.8 4.1 5.4 5.1 6.1 5.2 6.5 6.0 7.4 5.7 7. 5 5.9 7.8 5.8 7. 9 6.5
Outdoor
temperature
Indoor temperature
68°FDB / 59 °FWB 73°FDB / 61 °FWB 75°FDB / 63 °FWB 79°FDB / 64 °FWB 80°FDB / 67 °FWB 82°FDB / 68 °FWB 86°FDB / 72 °FWB 90°FDB / 73 °FWB
(°FDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
50
7.6 6.0 8.7 7.3 9.8 7. 6 10.4 8.7 12.0 8.5 12.6 8.9 14.7 9.3 15.3 10.3
59
7.6 6.0 8.7 7.3 9.8 7. 6 10.4 8.7 12.0 8.5 12.6 8.9 14.7 9.3 15.3 10.3
70
7.6 6.0 8.7 7.3 9.8 7. 6 10.4 8.7 12.0 8.5 12.6 8.9 14.7 9.3 15.3 10.3
73
7.6 6.0 8.7 7.3 9.8 7. 6 10.4 8.7 12.0 8.5 12.6 8.9 14.7 9.3 15.2 10.3
77
7.6 6.0 8.7 7.3 9.8 7. 6 10.4 8.7 12.0 8.5 12.6 8.9 14.7 9.3 15.0 10.2
81
7.6 6.0 8.7 7.3 9.8 7. 6 10.4 8.7 12.0 8.5 12.6 8.9 14.6 9.2 14.7 10.1
86
7.6 6.0 8.7 7.3 9.8 7. 6 10.4 8.7 12.0 8.5 12.6 8.9 14.3 9.1 14.4 10.0
91
7.6 6.0 8.7 7.3 9.8 7. 6 10.4 8.7 12.0 8.5 12.6 8.9 14.0 9.0 14.1 9.9
95
7.6 6.0 8.7 7.3 9.8 7. 6 10.4 8.7 12.0 8.5 12.6 8.9 13.7 8.9 13.9 9.8
99
7.6 6.0 8.7 7.3 9.8 7. 6 10.4 8.7 12.0 8.5 12.6 8.9 13.5 8.8 13.6 9.7
104
7.6 6.0 8.7 7.3 9.8 7. 6 10.4 8.7 12.0 8.5 12.6 8.9 13.2 8.7 13.3 9.6
109
7.6 6.0 8.7 7.3 9.8 7. 6 10.4 8.7 12.0 8.5 12.3 8.8 12.8 8.6 13.0 9.5
115
7.6 6.0 8.7 7.3 9.8 7. 6 10.4 8.7 11.8 8.4 11.9 8.7 12.5 8.4 12.6 9.3
Outdoor
temperature
Indoor temperature
68°FDB / 59 °FWB 73°FDB / 61 °FWB 75°FDB / 63 °FWB 79°FDB / 64 °FWB 80°FDB / 67 °FWB 82°FDB / 68 °FWB 86°FDB / 72 °FWB 90°FDB / 73 °FWB
(°FDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
50
8.9 7.5 10.2 9.2 11. 4 9.5 12 .1 10.9 14.0 10.5 14.6 11.1 17.2 11.5 17.9 12.8
59
8.9 7.5 10.2 9.2 11. 4 9.5 12 .1 10.9 14.0 10.5 14.6 11.1 17.2 11.5 17.9 12.8
70
8.9 7.5 10.2 9.2 11. 4 9.5 12 .1 10.9 14.0 10.5 14.6 11.1 17.2 11.5 17.9 12.8
73
8.9 7.5 10.2 9.2 11. 4 9.5 12 .1 10.9 14.0 10.5 14.6 11.1 17.2 11.5 17.8 12.8
77
8.9 7.5 10.2 9.2 11. 4 9.5 12 .1 10.9 14.0 10.5 14.6 11.1 17.2 11.5 17.5 12.7
81
8.9 7.5 10.2 9.2 11. 4 9.5 12 .1 10.9 14.0 10.5 14.6 11.1 17. 0 11.4 17. 2 12.6
86
8.9 7.5 10.2 9.2 11. 4 9.5 12 .1 10.9 14.0 10.5 14.6 11.1 16.7 11.3 16.8 12.4
91
8.9 7.5 10.2 9.2 11. 4 9.5 12 .1 10.9 14.0 10.5 14.6 11.1 16.3 11.1 16.5 12.3
95
8.9 7.5 10.2 9.2 11. 4 9.5 12 .1 10.9 14.0 10.5 14.6 11.1 16.0 11.0 16.2 12.2
99
8.9 7.5 10.2 9.2 11. 4 9.5 12 .1 10.9 14.0 10.5 14.6 11.1 15.7 10.9 15.9 12.1
104
8.9 7.5 10.2 9.2 11. 4 9.5 12 .1 10.9 14.0 10.5 14.6 11.1 15.4 10.8 15.5 12.0
109
8.9 7.5 10.2 9.2 11. 4 9.5 12 .1 10.9 14.0 10.5 14.4 10.9 15.0 10.7 15.1 11.8
115
8.9 7.5 10.2 9.2 11. 4 9.5 12 .1 10.9 13.8 10.4 13.9 10.8 14.5 10.5 14.7 11.7
- (02 - 36) -
