Fujitsu Airstage J-II Series User Manual

Note : Specications are based on the following conditions.
Cooling : Indoor temperature of 80°F(26.7°C)DB/67°F(19.4°C)WB,and outdoor temperature of 95.0°F(35°C)DB/75°F(23.9°C)WB.
Heating : Indoor temperature of 70°F(21.1°C)DB/60°F(15.6°C)WB,and outdoor temperature of 47°F(8.3°C)DB/43°F(6.1°C)WB.
Pipe length : 25ft.(7.5 m), Height difference : 0ft.(0 m) (Outdoor unit - Indoor unit).
The protective function might work when using it outside the operation range.
1-4. MINI DUCT TYPE
Model name ARUL4TLAV1
Power source 1 Phase ~ 208/230V 60Hz
Available voltage range 187 to 253 V
Capacity
Cooling
Btu/h 4,000
kW 1.2
Heating
Btu/h 4,400
kW 1.3
Input power
W
26
Static pressure range in.WG(Pa) 0 to 0.12 (0 to 30)
Standard static pressure in.WG(Pa) 0.04 (10)
Fan
Airow
rate
High
CFM
(m
3
/ h)
271 (460)
Med-Hi
259 (440)
Med
247 (420)
Lo-Hi
235 (400)
Low
218 (370)
Quiet
200 (340)
Type x Quantity Sirocco × 2
Motor output W 80
Sound pressure
level
High
dB(A)
25
Med-Hi
24
Med
23
Low-Hi
22
Low
21
Quiet
20
Heat exchanger Length in. (mm) 19-5/16 (490)
Fin pitch FPI 19
Rows x Stages 1 × 16
Face Area ft
2
. (m
2
) 1.7 (0.16)
Pipe type (Material) Grooved H-pin (Copper)
Fin Type (Material) Slit (Aluminum)
Surface treatment Hydrophilic coating
Air lter Type Fungicide type
Net material PP honeycomb
Enclosure Material Galvanized sheet iron
Color -
Dimensions
(H x W x D)
Net
in. (mm)
7-13/16 × 27-9/16 × 17-11/16 (198 × 700 × 450)
Gross 9-13/16 × 36-5/8 × 22-13/16 (250 × 930 × 580)
Weight Net
lbs. (kg)
32 (14.5)
Gross 40 (18)
Connection
pipe diameter
Liquid (Flare)
in. (mm)
ø 1/4 (6.35)
Gas (Flare) ø 3/8 (9.52)
Drain hose ø3/4 (19.05) [I.D.]; ø1-1/16 (26.6) [O.D.]
