2-2. INDOOR UNIT (setting by switch)
SWITCH POSITION
Type of PCB Type of Indoor unit
Type 1
Compact cassette, Cassette, Mini duct, Slim duct/Slim concealed oor,
Medium static pressure duct, High static pressure duct, Floor/ceiling, Ceiling,
Vertical air handler
Type 2
Wall mounted (ASUB18, 24)
Type 3 Wall mounted (ASUA7, 9, 12, 14TLAV)
Type 4 Circular ow cassette
Type 5 Wall mounted (ASUA4, 7, 9, 12, 14TLAV1)
Type 6 Wall mounted (ASUB30, 36)
Type 7 Compact oor
z
Type 1
SET1SET2
DIP switch
(type A)
SW1
Main PCB
DIP switch
(type B)
Rotary switch
(type C)
Rotary switch
(type D)
DIP switch
(type A)
SW601 SW602
SW604 SW605 SW606 SW607 SW608
SW PCB
- (07 - 79) -
FUNCTION
SETTING
FUNCTION
SETTING
