9. SAFETY DEVICES
Model and type Fuse
Fan motor thermal
protector
Terminal
thermal fuse
Float
switch
Compact cassette
AUUA4TLAV1
250V
3.15A
Activate at
280.4±27°F
(138±15°C):
Fan motor stop
Reset at
221±36°F
(105±20°C):
Fan motor restart
―
○
AUUA7TLAV
AUUA9TLAV
AUUA12TLAV
AUUA14TLAV
AUUA18TLAV
AUUA24TLAV
Circular ow cassette
AUUB18TLAV1
250V
3.15A
Activate at
257±18°F
(125±10°C):
Fan motor stop
Reset at
248±18°F
(120±10°C)
Fan motor restart
―
○
AUUB24TLAV1
AUUB30TLAV1
AUUB36TLAV1
AUUB48TLAV1
Cassette
(Slim type)
AUUB18TLAV
250V
3.15A
Activate at
230
+27
-18
°F
(110
+15
-10
°C):
Fan motor stop
Reset at
221
+27
-18
°F
(105+
15
-10
°C):
Fan motor restart
―
○
AUUB24TLAV
Cassette
AUUB30TLAV
AUUB36TLAV
Mini duct ARUL4TLAV1
250V
3.15A
Activate at
275±27°F
(135±15°C):
Fan motor stop
Reset at
239±27°F
(115±15°C):
Fan motor restart
―
○
Slim duct / slim
concealed oor
ARUL7TLAV
250V
5A
Activate at
275±27°F
(135±15°C):
Fan motor stop
Reset at
239±27°F
(115±15°C):
Fan motor restart
―
○
ARUL9TLAV
ARU L12 TL AV
ARU L14TL AV
ARUL18TLAV
Medium static
pressure duct
ARUM24TLAV
250V
5A
Activate at
275±27°F
(135±15°C):
Fan motor stop
Reset at
239±27°F
(115±15°C)
Fan motor restart
―

*
2
ARUM30TLAV
Activate at
239±27°F
(115±15°C):
Fan motor stop
Reset at
158°F or less
(70°C or less):
Fan motor restart
ARUM36TLAV
*
1
: Fuse for fan motor.
*
2
: Including in the Drain Pump Unit (Optional parts)
