Fujitsu Airstage J-II Series User Manual

TC : Total Capacity kBtu/h.
HEATING CAPACITY
in kBtu/h
8. CAPACITY TABLE HEATING (INDOOR UNIT)
8-1. COMPACT CASSETTE TYPE

MODEL : AUUA4TLAV1

MODEL : AUUA7TLAV

MODEL : AUUA9TLAV

MODEL : AUUA12TLAV
Outdoor Temperature
Indoor temperature
61°FDB 64°FDB 68°FDB 70°FDB 72°FDB 75°FDB 79°FDB
(°FDB)
(°FWB) TC TC TC TC TC TC TC
-2.7
-4.0
7.0 7.0 7.0 7.0 7.0 7. 0 6.9
5.0
3.2
8.1 8 .1 8.1 8.0 8.0 8.0 8.0
10.4
8.6
9.1 9.0 9.0 9.0 8.9 8.9 8.9
15.8
14.0
9.9 9.9 9.8 9.8 9.8 9.8 9.7
17. 0
15.0
10.1 10.1 10.0 10.0 10.0 9.9 9.9
23.0
21.2
11. 2 11. 2 11.1 11.1 11.0 11.0 10.9
26.6
24.8
11. 8 11. 8 11.7 11.7 11.6 11.6 11.0
30.2
28.4
12.4 12.4 12.3 12.2 12.2 12.1 11.0
32.0
30.2
12.7 12.6 12.6 12.5 12.5 12.1 11.0
35.6
33.8
13.3 13.2 13.2 13.1 12.8 12.1 11.0
41.0
39.2
14.4 14.3 14.0 13.5 12.9 12.2 11. 2
47.0
43.0
15.0 14.9 14.0 13.5 12.9 12.2 11.2
48.2
46.0
15.5 15.0 14.0 13.5 12.9 12.2 11. 2
53.6
51.1
15.8 15.0 14.0 13.5 12.9 12.2 11. 2
59.0
56.3
15.8 15.0 14.0 13.5 12.9 12.2 11. 2
Outdoor Temperature
Indoor temperature
61°FDB 64°FDB 68°FDB 70°FDB 72°FDB 75°FDB 79°FDB
(°FDB)
(°FWB) TC TC TC TC TC TC TC
-2.7
-4.0
5.7 5.7 5.7 5.6 5.6 5.6 5.6
5.0
3.2
6.6 6.5 6.5 6.5 6.5 6.5 6.5
10.4
8.6
7.3 7.3 7. 3 7. 3 7.2 7. 2 7. 2
15.8
14.0
8.0 8.0 7. 9 7. 9 7.9 7. 9 7.8
17. 0
15.0
8.1 8 .1 8.1 8.0 8.0 8.0 8.0
23.0
21.2
9.0 9.0 9.0 8.9 8.9 8.9 8.8
26.6
24.8
9.5 9.5 9.4 9.4 9.4 9.4 8.9
30.2
28.4
10.0 10.0 9.9 9.9 9.9 9.7 8.9
32.0
30.2
10.3 10.2 10.1 10.1 10.1 9.7 8.9
35.6
33.8
10.8 10.7 10.6 10.6 10.3 9.7 8.9
41.0
39.2
11. 6 11.6 11.3 10.9 10.5 9.8 9.0
47.0
43.0
12 .1 12.1 11.3 10.9 10.5 9.8 9.0
48.2
46.0
12.6 12.1 11. 3 10.9 10.5 9.8 9.0
53.6
51.1
12.8 12.1 11. 3 10.9 10.5 9.8 9.0
59.0
56.3
12.8 12.1 11. 3 10.9 10.5 9.8 9.0
Outdoor Temperature
Indoor temperature
61°FDB 64°FDB 68°FDB 70°FDB 72°FDB 75°FDB 79°FDB
(°FDB)
(°FWB) TC TC TC TC TC TC TC
-2.7
-4.0
4.9 4.9 4.9 4.9 4.9 4.9 4.9
5.0
3.2
5.7 5.7 5.7 5.7 5.7 5.7 5.6
10.4
8.6
6.4 6.4 6.3 6.3 6.3 6.3 6.3
15.8
14.0
7.0 7.0 6.9 6.9 6.9 6.9 6.8
17. 0
15.0
7.1 7.1 7. 0 7.0 7.0 7. 0 7.0
23.0
21.2
7.9 7.9 7. 8 7. 8 7.8 7.7 7.7
26.6
24.8
8.3 8.3 8.2 8.2 8.2 8.2 7. 8
30.2
28.4
8.7 8.7 8.6 8.6 8.6 8.5 7. 8
32.0
30.2
9.0 8.9 8.8 8.8 8.8 8.5 7. 8
35.6
33.8
9.4 9.3 9.3 9.2 9.0 8.5 7.8
41.0
39.2
10.1 10.1 9.9 9.5 9.1 8.6 7. 9
47.0
43.0
10.6 10.5 9.9 9.5 9.1 8.6 7. 9
48.2
46.0
10.9 10.6 9.9 9.5 9.1 8.6 7. 9
53.6
51.1
11.1 10.6 9.9 9.5 9.1 8.6 7.9
59.0
56.3
11.1 10.6 9.9 9.5 9.1 8.6 7.9
Outdoor Temperature
Indoor temperature
61°FDB 64°FDB 68°FDB 70°FDB 72°FDB 75°FDB 79°FDB
(°FDB)
(°FWB) TC TC TC TC TC TC TC
-2.7
-4.0
2.3 2.3 2.3 2.3 2.3 2.3 2.3
5.0
3.2
2.7 2.6 2.6 2.6 2.6 2.6 2.6
10.4
8.6
3.0 2.9 2.9 2.9 2.9 2.9 2.9
15.8
14.0
3.2 3.2 3.2 3.2 3.2 3.2 3.2
17. 0
15.0
3.3 3.3 3.3 3.2 3.2 3.2 3.2
23.0
21.2
3.7 3.6 3.6 3.6 3.6 3.6 3.6
26.6
24.8
3.8 3.8 3.8 3.8 3.8 3.8 3.6
30.2
28.4
4.0 4.0 4.0 4.0 4.0 3.9 3.6
32.0
30.2
4.2 4.1 4.1 4.1 4 .1 3.9 3.6
35.6
33.8
4.3 4.3 4.3 4.3 4.2 3.9 3.6
41.0
39.2
4.7 4.7 4.6 4.4 4.2 4.0 3.6
47.0
43.0
4.9 4.9 4.6 4.4 4.2 4.0 3.6
48.2
46.0
5.1 4.9 4.6 4.4 4.2 4.0 3.6
53.6
51.1
5.1 4.9 4.6 4.4 4.2 4.0 3.6
59.0
56.3
5.1 4.9 4.6 4.4 4.2 4.0 3.6
