TC : Total Capacity kBtu/h.
SHC : Sensible Heat Capacity kBtu/h.
COOLING CAPACITY
in kBtu/h

MODEL : ASUB18TLAV

MODEL : ASUB24TLAV
Outdoor
temperature
Indoor temperature
68°FDB / 59 °FWB 73°FDB / 61 °FWB 75°FDB / 63 °FWB 79°FDB / 64 °FWB 80°FDB / 67 °FWB 82°FDB / 68 °FWB 86°FDB / 72 °FWB 90°FDB / 73 °FWB
(°FDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
50
15.2 12.2 17.4 14.9 19.6 15.4 20.7 17.7 24.0 17.1 25.1 18.0 29.5 18.7 30.6 20.8
59
15.2 12.2 17.4 14.9 19.6 15.4 20.7 17.7 24.0 17.1 25.1 18.0 29.5 18.7 30.6 20.8
70
15.2 12.2 17.4 14.9 19.6 15.4 20.7 17.7 24.0 17.1 25.1 18.0 29.5 18.7 30.6 20.8
73
15.2 12.2 17.4 14.9 19.6 15.4 20.7 17.7 24.0 17.1 25.1 18.0 29.5 18.7 30.5 20.8
77
15.2 12.2 17.4 14.9 19.6 15.4 20.7 17.7 24.0 17.1 25.1 18.0 29.5 18.7 30.0 20.6
81
15.2 12.2 17.4 14.9 19.6 15.4 20.7 17.7 24.0 17.1 25.1 18.0 29.2 18.6 29.5 20.4
86
15.2 12.2 17.4 14.9 19.6 15.4 20.7 17.7 24.0 17.1 25.1 18.0 28.6 18.4 28.9 20.2
91
15.2 12.2 17.4 14.9 19.6 15.4 20.7 17.7 24.0 17.1 25.1 18.0 2 7.9 18.2 28.2 20.0
95
15.2 12.2 17.4 14.9 19.6 15.4 20.7 17.7 24.0 17.1 25.1 18.0 2 7.5 18.0 27.7 19.8
99
15.2 12.2 17.4 14.9 19.6 15.4 20.7 17.7 24.0 17.1 25.1 18.0 2 7.0 17.8 2 7.2 19.6
104
15.2 12.2 17.4 14.9 19.6 15.4 20.7 17.7 24.0 17.1 25.1 18.0 26.3 17.6 26.6 19.4
109
15.2 12.2 17.4 14.9 19.6 15.4 20.7 17.7 24.0 17.1 24.6 17.8 25.7 17.3 26.0 19.1
115
15.2 12.2 17.4 14.9 19.6 15.4 20.7 17.7 23.6 17.0 23.8 17.5 24.9 17.1 25.2 18.9
Outdoor
temperature
Indoor temperature
68°FDB / 59 °FWB 73°FDB / 61 °FWB 75°FDB / 63 °FWB 79°FDB / 64 °FWB 80°FDB / 67 °FWB 82°FDB / 68 °FWB 86°FDB / 72 °FWB 90°FDB / 73 °FWB
(°FDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
50
11. 4 9.2 13.1 11.2 14.7 11.7 15.5 13.4 18.0 12.9 18.8 13.6 2 2 .1 14.2 23.0 15.7
59
11. 4 9.2 13.1 11.2 14.7 11.7 15.5 13.4 18.0 12.9 18.8 13.6 2 2 .1 14.2 23.0 15.7
70
11. 4 9.2 13.1 11.2 14.7 11.7 15.5 13.4 18.0 12.9 18.8 13.6 2 2 .1 14.2 23.0 15.7
73
11. 4 9.2 13.1 11.2 14.7 11.7 15.5 13.4 18.0 12.9 18.8 13.6 2 2 .1 14.2 22.8 15.7
77
11. 4 9.2 13.1 11.2 14.7 11.7 15.5 13.4 18.0 12.9 18.8 13.6 2 2 .1 14.2 22.5 15.6
81
11. 4 9.2 13.1 11.2 14.7 11.7 15.5 13.4 18.0 12.9 18.8 13.6 21.9 14.1 22.1 15.4
86
11. 4 9.2 13.1 11.2 14.7 11.7 15.5 13.4 18.0 12.9 18.8 13.6 21.4 13.9 21.6 15.3
91
11. 4 9.2 13.1 11.2 14.7 11.7 15.5 13.4 18.0 12.9 18.8 13.6 21.0 13.7 21.2 15 .1
95
11. 4 9.2 13.1 11.2 14.7 11.7 15.5 13.4 18.0 12.9 18.8 13.6 20.6 13.6 20.8 15.0
99
11. 4 9.2 13.1 11.2 14.7 11.7 15.5 13.4 18.0 12.9 18.8 13.6 20.2 13.5 20.4 14.8
104
11. 4 9.2 13.1 11.2 14.7 11.7 15.5 13.4 18.0 12.9 18.8 13.6 19.7 13.3 19.9 14.7
109
11. 4 9.2 13.1 11.2 14.7 11.7 15.5 13.4 18.0 12.9 18.5 13.5 19.3 13 .1 19.5 14.5
115
11. 4 9.2 13.1 11.2 14.7 11.7 15.5 13.4 17.7 12.8 17.9 13.2 18.7 12.9 18.9 14.3
