Fujitsu Airstage J-II Series User Manual

2-11. IR RECEIVER UNIT
(for CASSETTE TYPE)

MODEL: UTY-LRHYB1
Cassette type indoor unit can be controlled with wireless remote controller
if the IR receiver unit is used.

FUNCTIONS

ELECTRICAL WIRING
Filter lamp (Red)
Timer lamp (Orange)
Operation lamp (Green)
Manual auto
Signal receiver
Indoor unit (Cassette type)
Wiring hole
Wire from IR Receiver unit
IR Receiver unit
Connected to
CN18 of PCB
- (05 - 94) -
CONTROL SYSTEM CONTROL SYSTEM
