DIMENSIONS

PACKING LIST
Name and shape Quantity
Application
Installation manual 1
Strap 1 Prevent receiver kit from falling down

SPECIFICATIONS
Model name UT Y-LRHYB1
Dimensions [H
×
W
×
D]: in. (mm)
7-5/8 × 7-5/8 × 1-1/4 (193.9 × 193.9 × 31.2)
Weight: oz. (g) 5 (140)
7-5/8 (193.9)
7-5/8 (193.9)
1-1/4 (31.2)
Front View
Side View
Unit : in. (mm)
- (05 - 95) -
