2-1-3. V-II (460V) series

SETTINGS LIST
LED105
CODE
No.
Setting Mode
LED104
CODE No.
Setting Function
Factory
setting
Outdoor unit
Remarks
Master Slave
0 0
Pipe length
setting
0 0
Standard (131 to 213ft.)
(40 to 65m)
l
¡
-
*1
Pipe length means the length
between master outdoor unit
and the nearest indoor unit.
0 1
Short (less than 131ft.)
(less than 40m)
0 2
Medium (213 to 295ft.)
(65 to 90m)
0 3
Long 1 (295 to 394ft.)
(90 to 120m)
0 4
Long 2 (394 to 541ft.)
(120 to 165m)
1 0
Sequential start
shift
0 0 Normal
l
¡
-
*1
The start-up timing of outdoor
unit (compressor) can be set
up so that it can delay several
seconds.
This feature is useful when
multiple number of outdoor units
are installed and turned on at
the same time
to limit the starting current.
0 1 21sec. Delay
0 2 42sec. Delay
0 3 63sec. Delay
1 1
Cooling
capacity shift
0 0 Normal mode
l
¡
-
*1
0 1 Save energy mode
0 2 High power mode 1
0 3 High power mode 2
0 4 Prohibited
1 2
Heating
capacity shift
0 0 Normal mode
l
¡
-
*1
0 1 Save energy mode
0 2 High power mode 1
0 3 High power mode 2
1 3 Prohibited
0 0 Prohibited
l
Setting prohibited
0 1 Prohibited
1 7
Height
di󰀨erence
between indoor
units
0 0 Standard
l
¡
-
*1
If installing the indoor units (even
only one set) to a lower oor
than the outdoor unit, and the
height di󰀨erence between the
indoor units is 3m or greater (i.e.,
if installing the indoor units on
separate oors), set "02 (height
di󰀨erence)".
0 1 Prohibited
0 2 Height di󰀨erence
0 3 Prohibited
0 4 Prohibited
*1: Do not set this for outdoor units with Slave setting.
