Note : Specications are based on the following conditions.
Cooling : Indoor temperature of 80°F(26.7°C)DB/67°F(19.4°C)WB,and outdoor temperature of 95.0°F(35°C)DB/75°F(23.9°C)WB.
Heating : Indoor temperature of 70°F(21.1°C)DB/60°F(15.6°C)WB,and outdoor temperature of 47°F(8.3°C)DB/43°F(6.1°C)WB.
Pipe length : 25ft.(7.5 m), Height difference : 0ft.(0 m) (Outdoor unit - Indoor unit).
The protective function might work when using it outside the operation range.
Model name AUUB30TLAV AUUB36TLAV
Power source 1 Phase ~ 208/230V 60Hz
Available voltage range 187 to 253 V
Capacity
Cooling
Btu/h 30,000 36,000
kW 8.8 10.6
Heating
Btu/h 34,000 40,000
kW 10.0 11.7
Input power W 59 80
Fan
Airow rate
High
CFM
(m
3
/ h)
942
(1,600)
1,059
(1,800)
Med
765
(1,300)
765
(1,300)
Low
647
(1,100)
647
(1,100)
Type x Quantity Turbo × 1
Motor output W 80
Sound pressure
level
High
dB(A)
40 44
Med 38 38
Low 33 33
Heat exchanger Length in. (mm) 81-15/16 (2,082)
Fin pitch FPI 19
Rows x Stages 3 × 12
Face Area ft
2
. (m
2
) 5.6 (0.52)
Pipe type (Material) Grooved H-pin (Copper)
Fin Type (Material) Slit(Aluminum)
Surface treatment Hydrophilic coating
Air lter Type Anti-mold
Net material PP honeycomb
Enclosure Material Galvanized sheet iron
Color -
Dimensions
(H x W x D)
Net
in. (mm)
11-5/16 × 33-1/16 × 33-1/16 (288 × 840 × 840)
Gross 14-3/16 × 37-13/16 × 38-9/16 (360 × 960 × 980)
Weight Net
lbs. (kg)
60 (27)
Gross 73 (33)
Connection
pipe diameter
Liquid (Flare)
in. (mm)
ø 3/8 (9.52)
Gas (Flare) ø 5/8 (15.88) ø 3/4 (19.05)
Drain hose ø3/4 (19.05) [I.D.]; ø1-1/16 (26.6) [O.D.]
Cassette Grille
Model name UTG-LCGV
Color WHITE
Approximate color of MUNSELL N9.25
Dimensions
(H x W x D)
Net
in. (mm)
1-15/16 × 37-3/8 × 37-3/8 (50 × 950 × 950)
Gross 4-1/2 × 40-3/16 × 39-3/8 (115 × 1,020 × 1,000)
Weight Net
lbs. (kg)
13 (5.5)
Gross 19 (8.5)
- (04-05) -
