Fujitsu Airstage J-II Series User Manual

HEATING CAPACITY
TC : Total Capacity kBtu/h.
IP : Input Power kW (Compressor + Outdoor fan motor).
The data is based on the following conditions. Pipe length : 25 ft. (7.5 m) , Height di󰀨erence : 0 ft. (0 m).

MODEL : AOU36RLAVM
z
Capacity : 42 kBtu/h (3 ton)
Total rated
cooling capacity
of indoor unit
Outdoor temperature
Indoor temperature
61°FDB 64°FDB 68°FDB 70°FDB 72°FDB 75°FDB 79°FDB
(°FDB)
(°FWB) TC IP TC IP TC IP TC IP TC IP TC IP TC IP
33.6
(80%)
-4.0
-5.3
33.6 3.68 33.6 3.77 33.6 3.89 33.6 3.95 32.3 4.01 30.4 3.91 27.8 3.58
5.0
3.2
37.8 4.02 3 7.5 4.12 34.9 4.20 33.6 4.04 32.3 3.88 30.4 3.65 2 7.8 3.33
10.4
8.6
39.4 4.27 37.5 4.30 34.9 3.99 33.6 3.84 32.3 3.69 30.4 3.47 2 7.8 3.17
15.8
14.0
39.4 4.22 37.5 4.00 34.9 3.72 33.6 3.58 32.3 3.44 30.4 3.23 2 7.8 2.95
17. 0
15.0
39.4 4.14 37.5 3.93 34.9 3.65 33.6 3.51 32.3 3.37 30.4 3.17 2 7.8 2.89
23.0
21.2
39.4 3.81 37.5 3.62 34.9 3.36 33.6 3.23 32.3 3.10 30.4 2.91 2 7. 8 2.66
26.6
24.8
39.4 3.60 37.5 3.41 34.9 3 .17 33.6 3.05 32.3 2.93 30.4 2.75 2 7.8 2.51
30.2
28.4
39.4 3.43 37. 5 3.25 34.9 3.02 33.6 2.91 32.3 2.79 30.4 2.62 27. 8 2.40
32.0
30.2
39.4 3.36 37. 5 3.19 34.9 2.96 33.6 2.85 32.3 2.74 30.4 2.57 2 7.8 2.35
35.6
33.8
39.4 3.24 37. 5 3.07 34.9 2.85 33.6 2.74 32.3 2.63 30.4 2.47 27. 8 2.26
41.0
39.2
39.4 3.05 37.5 2.89 34.9 2.69 33.6 2.59 32.3 2.48 30.4 2.33 27.8 2.13
47.0
43.0
39.4 2.93 37. 5 2.78 34.9 2.58 33.6 2.48 32.3 2.38 30.4 2.24 27. 8 2.05
48.2
46.0
39.4 2.83 37. 5 2.69 34.9 2.50 33.6 2.40 32.3 2.31 30.4 2.17 2 7.8 1.98
53.6
51.1
39.4 2.68 37.5 2.54 34.9 2.36 33.6 2.27 32.3 2.19 30.4 2.05 27.8 1.88
59.0
56.3
39.4 2.53 37. 5 2.41 34.9 2.23 33.6 2 .15 32.3 2.07 30.4 1.94 27.8 1.78
29.4
(70%)
-4.0
-5.3
33.6 3.89 32.8 3.98 30.5 3.93 29.4 3.79 28.3 3.64 26.6 3.42 24.3 3 .14
5.0
3.2
34.5 4.15 32.8 3.94 30.5 3.67 29.4 3.53 28.3 3.39 26.6 3.19 24.3 2.92
10.4
8.6
34.5 3.95 32.8 3.75 30.5 3.49 29.4 3.36 28.3 3.23 26.6 3.03 24.3 2.78
15.8
14.0
34.5 3.68 32.8 3.49 30.5 3.25 29.4 3 .12 28.3 3.00 26.6 2.82 24.3 2.58
17. 0
15.0
34.5 3.60 32.8 3.42 30.5 3 .18 29.4 3.06 28.3 2.94 26.6 2.77 24.3 2.53
23.0
21.2
34.5 3.32 32.8 3 .15 30.5 2.93 29.4 2.82 28.3 2.71 26.6 2.55 24.3 2.33
26.6
24.8
34.5 3.13 32.8 2.97 30.5 2.77 29.4 2.66 28.3 2.56 26.6 2.40 24.3 2.20
30.2
28.4
34.5 2.98 32.8 2.83 30.5 2.64 29.4 2.54 28.3 2.44 26.6 2.29 24.3 2 .10
32.0
30.2
34.5 2.93 32.8 2.78 30.5 2.58 29.4 2.49 28.3 2.39 26.6 2.25 24.3 2.06
35.6
33.8
34.5 2.82 32.8 2.67 30.5 2.49 29.4 2.39 28.3 2.30 26.6 2 .16 24.3 1.98
41.0
39.2
34.5 2.66 32.8 2.52 30.5 2.35 29.4 2.26 28.3 2 .17 26.6 2.04 24.3 1.87
47.0
43.0
34.5 2.55 32.8 2.42 30.5 2.25 29.4 2.17 28.3 2.08 26.6 1.96 24.3 1.79
48.2
46.0
34.5 2.47 32.8 2.34 30.5 2.18 29.4 2.10 28.3 2.02 26.6 1.90 24.3 1.74
53.6
51.1
34.5 2.34 32.8 2.22 30.5 2.06 29.4 1.99 28.3 1.91 26.6 1.80 24.3 1.65
59.0
56.3
34.5 2.21 32.8 2.10 30.5 1.95 29.4 1.88 28.3 1.81 26.6 1.70 24.3 1.56
25.2
(60%)
-4.0
-5.3
29.6 3.81 28 .1 3.62 26.2 3.37 25.2 3.25 24.2 3.13 22.8 2.94 20.8 2.70
5.0
3.2
29.6 3.55 28.1 3.37 26.2 3.14 25.2 3.03 24.2 2.91 22.8 2.74 20.8 2.51
10.4
8.6
29.6 3.38 28.1 3.21 26.2 2.99 25.2 2.88 24.2 2.77 22.8 2.60 20.8 2.39
15.8
14.0
29.6 3.14 2 8 .1 2.99 26.2 2.78 25.2 2.68 24.2 2.57 22.8 2.42 20.8 2.22
17. 0
15.0
29.6 3.08 28 .1 2.93 26.2 2.73 25.2 2.62 24.2 2.52 22.8 2.37 20.8 2.18
23.0
21.2
29.6 2.84 28.1 2.69 26.2 2.51 25.2 2.42 24.2 2.32 22.8 2.19 20.8 2.00
26.6
24.8
29.6 2.68 28 .1 2.54 26.2 2.37 25.2 2.28 24.2 2.19 22.8 2.06 20.8 1.89
30.2
28.4
29.6 2.55 28.1 2.42 26.2 2.26 25.2 2 .17 24.2 2.09 22.8 1.97 20.8 1.80
32.0
30.2
29.6 2.50 28.1 2.38 26.2 2.21 25.2 2.13 24.2 2.05 22.8 1.93 20.8 1.77
35.6
33.8
29.6 2.41 28.1 2.29 26.2 2 .13 25.2 2.05 24.2 1.97 22.8 1.86 20.8 1.70
41.0
39.2
29.6 2.27 28 .1 2.16 26.2 2.01 25.2 1.94 24.2 1.86 22.8 1.75 20.8 1.61
47.0
43.0
29.6 2.18 2 8 .1 2.07 26.2 1.93 25.2 1.86 24.2 1.79 22.8 1.68 20.8 1.55
48.2
46.0
29.6 2 .11 2 8.1 2.01 26.2 1.87 25.2 1.80 24.2 1.73 22.8 1.63 20.8 1.50
53.6
51.1
29.6 2.00 28 .1 1.90 26.2 1.77 25.2 1.71 24.2 1.64 22.8 1.55 20.8 1.42
59.0
56.3
29.6 1.89 2 8 .1 1.80 26.2 1.68 25.2 1.61 24.2 1.55 22.8 1.46 20.8 1.35
21.0
(50%)
-4.0
-5.3
24.6 3.18 23.4 3.02 21.8 2.82 21.0 2.72 20.2 2.62 19.0 2.46 17.4 2.26
5.0
3.2
24.6 2.96 23.4 2.81 21.8 2.62 21.0 2.53 20.2 2.43 19.0 2.29 17. 4 2.10
10.4
8.6
24.6 2.81 23.4 2.67 21.8 2.49 21.0 2.40 20.2 2.31 19.0 2.18 17.4 2.00
15.8
14.0
24.6 2.61 23.4 2.49 21.8 2.32 21.0 2.23 20.2 2.15 19.0 2.03 17.4 1.86
17. 0
15.0
24.6 2.56 23.4 2.44 21.8 2.27 21.0 2 .19 20.2 2.11 19.0 1.99 17.4 1.82
23.0
21.2
24.6 2.36 23.4 2.24 21.8 2.09 21.0 2.02 20.2 1.94 19.0 1.83 17.4 1.68
26.6
24.8
24.6 2.23 23.4 2 .12 21.8 1.98 21.0 1.90 20.2 1.83 19.0 1.73 17. 4 1.59
30.2
28.4
24.6 2 .12 23.4 2.02 21.8 1.88 21.0 1.82 20.2 1.75 19.0 1.65 17.4 1.51
32.0
30.2
24.6 2.08 23.4 1.98 21.8 1.85 21.0 1.78 20.2 1.71 19.0 1.62 17. 4 1.48
35.6
33.8
24.6 2.00 23.4 1.91 21.8 1.78 21.0 1.71 20.2 1.65 19.0 1.56 17. 4 1.43
41.0
39.2
24.6 1.89 23.4 1.80 21.8 1.68 21.0 1.62 20.2 1.56 19.0 1.47 17. 4 1.35
47.0
43.0
24.6 1.82 23.4 1.73 21.8 1.61 21.0 1.55 20.2 1.50 19.0 1.41 17. 4 1.30
48.2
46.0
24.6 1.76 23.4 1.67 21.8 1.56 21.0 1.51 20.2 1.45 19.0 1.37 17.4 1.26
53.6
51.1
24.6 1.67 23.4 1.59 21.8 1.48 21.0 1.43 20.2 1.38 19.0 1.30 17. 4 1.19
59.0
56.3
24.6 1.58 23.4 1.50 21.8 1.40 21.0 1.35 20.2 1.30 19.0 1.23 17.4 1.13
- (02 - 22) -
MODEL SELECTION MODEL SELECTION
