Fujitsu Airstage J-II Series User Manual


DIMENSIONS
2-3/16
(55.3)
6-1/2
(164.5)
6-1/2
(164.5)
7/8
(22.6)
Front View Side View
Unit: in. (mm)

PACKING LIST
Name and shape Quantity
Application
IR receiver unit
1
For receiving the
signal from the remote
control unit
Strap 1
Prevent IR receiver unit
from falling down
Cable tie 2 For electrical wiring

SPECIFICATIONS
Model name UTY - LBHXD
Dimensions [H × W × D]: in. (mm) 6-1/2 × 6-1/2 × 7/8 (164.5 × 164.5 × 22.6)
Weight: oz. (g) 4 (110)
- (05 - 97) -
CONTROL SYSTEM CONTROL SYSTEM
