Note : Specications are based on the following conditions.
Cooling : Indoor temperature of 80°F(26.7°C)DB/67°F(19.4°C)WB,and outdoor temperature of 95.0°F(35°C)DB/75°F(23.9°C)WB.
Heating : Indoor temperature of 70°F(21.1°C)DB/60°F(15.6°C)WB,and outdoor temperature of 47°F(8.3°C)DB/43°F(6.1°C)WB.
Pipe length : 25ft.(7.5 m), Height difference : 0ft.(0 m) (Outdoor unit - Indoor unit).
The protective function might work when using it outside the operation range.
Model name AUUA18TLAV AUUA24TLAV
Power source 1 Phase ~ 208/230V 60Hz
Available voltage range 187 to 253 V
Capacity
Cooling
Btu/h 18,000 24,000
kW 5.3 7.0
Heating
Btu/h 20,000 27,000
kW 5.9 7.9
Input power W 36 84
Fan
Airow rate
High
CFM
(m
3
/ h)
418
(710)
606
(1,030)
Med
341
(580)
489
(830)
Low
235
(400)
265
(450)
Type x Quantity Turbo × 1
Motor output W 54
Sound
pressure
level
High
dB(A)
41 50
Med 35 44
Low 27 30
Heat
exchanger
Length in. (mm) 51-9/16 (1,310)
Fin pitch FPI 19
Rows x Stages 3 × 10
Face Area ft
2
. (m
2
) 3.0 (0.28)
Pipe type (Material) Grooved H-pin (Copper)
Fin
Type (Material) Slit(Aluminum)
Surface treatment Hydrophilic coating
Air lter
Type Anti-mold
Net material PP honeycomb
Enclosure
Material Galvanized sheet iron
Color -
Dimensions
(H x W x D)
Net
in. (mm)
9-5/8 × 22-7/16 × 22-7/16 (245 × 570 × 570)
Gross 10-7/16 × 28-3/4 × 24-5/8 (265 × 730 × 625)
Weight
Net
lbs. (kg)
37 (17)
Gross 44 (20)
Connection
pipe
diameter
Liquid (Flare)
in. (mm)
ø 3/8 (9.52)
Gas (Flare) ø 5/8 (15.88)
Drain hose ø3/4 (19.05) [I.D.]; ø1-1/16 (26.6) [O.D.]
Cassette
Grille
(Grid type)
Model name UTG-CCGVG
Color
WHITE
Approximate color of MUNSELL 9PB 9.1/0.2
Dimensions
(H x W x D)
Net
in. (mm)
1-15/16 × 24-7/16 × 24-7/16 (50 × 620 × 620)
Gross 4-3/4 × 30-1/8 × 29-3/4 (120 × 765 × 755)
Weight
Net
lbs. (kg)
5 (2.3)
Gross 10 (4.5)
Cassette
Grille
(Standard
type)
Model name UTG-CCGV
Color
WHITE
Approximate color of MUNSELL N9.25
Dimensions
(H x W x D)
Net
in. (mm)
1-15/16 × 27-9/16 × 27-9/16 (50 × 700 × 700)
Gross 4-3/4 × 30-1/8 × 29-3/4 (120 × 765 × 755)
Weight
Net
lbs. (kg)
6 (2.6)
Gross 10 (4.5)
- (04-02) -
