Fujitsu Airstage J-II Series User Manual

Note : Specications are based on the following conditions.
Cooling : Indoor temperature of 80°F(26.7°C)DB/67°F(19.4°C)WB,and outdoor temperature of 95.0°F(35°C)DB/75°F(23.9°C)WB.
Heating : Indoor temperature of 70°F(21.1°C)DB/60°F(15.6°C)WB,and outdoor temperature of 47°F(8.3°C)DB/43°F(6.1°C)WB.
Pipe length : 25ft.(7.5 m), Height difference : 0ft.(0 m) (Outdoor unit - Indoor unit).
The protective function might work when using it outside the operation range.
Model name ARUL18TLAV
Power source 1 Phase ~ 208/230V 60Hz
Available voltage range 187 to 253 V
Capacity
Cooling
Btu/h 18,000
kW 5.3
Heating
Btu/h 20,000
kW 5.9
Input power W 83
Static pressure range in.WG(Pa) 0 to 0.36 (0 to 90)
Standard static pressure in.WG(Pa) 0.10 (25)
Fan
Airow rate
High
CFM
(m
3
/ h)
553
(940)
Med
494
(840)
Low
441
(750)
Type x Quantity Sirocco × 3
Motor output W 81
Sound pressure
level
High
dB(A)
34
Med 32
Low 28
Heat exchanger Length in. (mm) 27-9/16 (700)
Fin pitch FPI 19
Rows x Stages 3 × 14
Face Area ft
2
. (m
2
) 2.3 (0.21)
Pipe type (Material) Grooved H-pin (Copper)
Fin Type (Material) Slit(Aluminum)
Surface treatment Hydrophilic coating
Air lter Type Fungicide type
Net material PP honeycomb
Enclosure Material Galvanized sheet iron
Color -
Dimensions
(H x W x D)
Net
in. (mm)
7-13/16 × 35-7/16 × 24-7/16
(198 × 900 × 620)
Gross 10-7/8 × 46 × 30-3/8
(276 × 1,168 × 772)
Weight Net
lbs. (kg)
49 (22)
Gross 60 (27)
Connection
pipe diameter
Liquid (Flare)
in. (mm)
ø 3/8 (9.52)
Gas (Flare) ø 5/8 (15.88)
Drain hose ø3/4 (19.05) [I.D.]; ø1-1/16 (26.6) [O.D.]
