Fujitsu Airstage J-II Series User Manual

Unit : in. (mm)
3. DIMENSIONS
3-1. COMPACT CASSETTE TYPE

MODELS : AUUA4TLAV1, AUUA7TLAV, AUUA9TLAV, AUUA12TLAV,
AUUA14TLAV, AUUA18TLAV, AUUA24TLAV
AUUA4, AUUA7, AUUA9,
AUUA12, AUUA14
AUUA18, AUUA24

Refrigerant pipe are
connection
Liquid ø 1/4 (6.35) ø 3/8 (9.52)

Gas ø 1/2 (12.70) ø 5/8 (15.88)

Drain hose ø 3/4 (I.D.), ø 1-1/16 (O.D.)
11-1/4 (285) 11-1/4 (285)
Ceiling
4-1/2 (114)
4-1/2 (114)
B
27-9/16 (700)
27-9/16 (700)
View A
IR reciever
22-7/16 (570): Indoor unit
14-9/16 (370)
21-1/4 (540)
Hanging bolt position
a (Ceiling openings)
20-7/8 (530)
20-7/8 (530)
Hanging bolt position
Drain hose
A
View B
View C
8-7/162 (215)
3/4 (19)
1-3/16 (30)
4-13/16 (123)
1-3/16 (30)
10-5/16 (262)
7-3/16 (183)
Control Box


5-13/16 (146)
1-9/16 (40)
C
Cassette grille
24-7/16 (620)
24-7/16 (620)
IR receiver
Grid type grille
Standard type grille
a
(580 to 660) (580 to 610)
Standard type Grid type
22-13/16 to 26 22-13/16 to 24
- (04-24) -
INDOOR UNITS INDOOR UNITS
