Fujitsu Airstage J-II Series User Manual


MODELS: ARUV48TLAV, ARUV60TLAV
ARUV48, ARUV60

Refrigerant pipe are
connection
Liquid ø 3/8 (9.52)

Gas ø 3/4 (19.05)

Drain port - ø 3/4 (I.D.)
Front view
Top view
Bottom view
Side view
4-7/8 (124)
3-3/16 (81)
2-15/16 (74)
4-3/16 (107)
25-1/8 (638)
23-13/16 (605)
1-1/2 (38)
12-3/16 (310)
20 (508)
1-13/16 (46)
13-1/2 (343)
21-7/16 (544)
5 (127)
5-5/16 (135)
13-3/16 (335)
16-1/8 (409)
57-1/2 (1461)
1-1/8 (28)
Unit : in. (mm)
- (04-50) -
INDOOR UNITS INDOOR UNITS
