INSTALLATION LOCATION
Unit : in. (mm)
3-15/16 (100) hole
3-15/16 (100)
4-15/16 (50) hole
4-15/16 (125)
25-13/16 (655)
20-7/8 (530)
1-3/4 (45)
2-9/16 (65)
19-11/16 (500)
9-5/8
(245)
39 (990)
2-9/16 (65)
Wall bracket
Side of set
Ceiling
Left
Indoor unit
Right
6 (150) or more 12 (300) or more
Left Right
12 (300) or more12 (300) or more
Ceiling
91 (2300)
or more
Floor
1 (20)
or more
- (04-55) -
INDOOR UNITS INDOOR UNITS
