Fujitsu Airstage J-II Series User Manual

Unit : in. (mm)
ASUB18 ASUB24

Refrigerant pipe are
connection
Liquid ø 1/4 (6.35) ø 3/8 (9.52)

Gas ø 1/2 (12.70) ø 5/8 (15.88)

Drain hose
I.D. 1/2 (12) , O.D. 5/8 (16)
Drain hose : L=26-3/8 (670)

MODELS: ASUB18TLAV1, ASUB24TLAV1
39-5/16 (998)
Outline of unit
18-9/16 (471)
2-5/8 (67)
1-1/8 (28)
1-13/16 (46)
17-1/4 (438)2-3/8 (61) 4 (102)15-5/8 (397)
17 (432)
2-3/16 (56)
2-3/16 (56)
3/8 (10)
12-5/8 (320)
11/16 (17)
Ø 3-1/8 (80) hole
Piping inlet
Ø 3-1/8 (80) hole
Piping inlet
39-5/16 (998) 9 (238)
12-5/8 (320)
20-1/2 (520)
23-1/4 (590)
28-3/8 (721)
1 (25)
Ø 1-1/4 (32)
Ø 5/8 (16)
Ø 1/2 (12)
- (04-62) -
INDOOR UNITS INDOOR UNITS
