Unit : in. (mm)
ASUB30, ASUB36

Refrigerant pipe are
connection
Liquid ø 3/8 (9.52)

Gas ø 5/8 (15.88)

Drain hose
I.D. 9/16 (13.8) , O.D. 5/8 to 11/16 (15.8 to 16.7)
Drain hose : L=23-5/8 (600)

MODELS: ASUB30TLAV1, ASUB36TLAV1
45-1/4 (1150)
Outline of unit
20-1/2 (520)
18-7/8 (479)
4-1/4
(108)
19-3/4 (502)
1-15/16
(50)
7/16 (11)
13-3/8
(340)
ø3-1/8
(80)
20-1/2 (520)
3-9/16 (90)
13/16 (21)
2-1/2 (64)
5/8 (16)
2-3/8
(61)
1-15/16
(50)
ø3-1/8
(80)
45-1/4 (1150)
11 (280)
1/8 (3)
13-3/8 (340)
24-7/16 (621)
26-9/16 (674)
28-9/16 (725)
ø11/16 (16.7)
7/8 (22)
- (04-64) -
