Fujitsu Airstage J-II Series User Manual


MODELS : ASUA7TLAV, ASUA9TLAV, ASUA12TLAV,
ASUA14TLAV
ASUA7, ASUA9, ASUA12, ASUA14

Refrigerant pipe are
connection
Liquid ø 1/4 (6.35)

Gas ø 1/2 (12.70)

Drain hose -
ø 9/16 (I.D.), ø 5/8 to 11/16 (O.D.)
[ø 13.8 (I.D.), ø 15.8 to 16.7 (O.D.)]
Total length : 23-5/8 (600)
Unit : in. (mm)
10-13/16 (275)
31-1/8 (790)
20-7/8 (530)
18-1/2 (470)
26 (660)
20-7/8 (530)
18-1/2 (470)
15/16 (24)
11/16 (16.7)
8-7/16 (215)
14-7/8 (378) 16-1/4 (412)
9-15/16 (252.5)
8-1/16 (204)
7/16 (11)
4 (101)
5-15/16 (151)
8-11/16 (221)
9-1/2 (241)
ø 4 (80) or more
for pipe inlet
1 x 3/16 (25 x 5) (hole)
for bolt
12-1/2 (318)
10-15/16 (278)
13-1/2 (343)
7-1/2 (191) 9-7/16 (240)
4-3/4 (121)
6-3/4 (171)
8-15/16 (227)
3/16 x 15/16 (5 x 24) (hole)
for bolt
3/16 x 3/4 (5 x 19)
(hole) for bolt
60- ø3/16 (5) (hole)
for lapping screw
10-5/8 (270)
10-13/16 (275)
ø 4 (80) or more
for pipe inlet
- (04-66) -
INDOOR UNITS INDOOR UNITS
